CSX200 Configuration with QuickSET
The following section defines the Time Slots field in the Wide Area PPP Time Slot configuration
window.
A full line consists of 24 Time Slots (T1 and DI) or 31 Time Slots (E1) that are
Time Slots —
each capable of up to 64 Kbps throughput. Using the PPP Protocol, up to 24 interfaces (T1 and DI)
or 31 interfaces (E1) can be assigned to the WAN link. Using the pull-down menu to the right of
each Time Slot field, select the interface number that you wish to assign to the Time Slot.
If you are configuring a WPIM-DI Time Slot table, any available Time Slots that are set
NOTE
to "00" are mapped to the DI Interface. In other words, If you lease an entire T1 line,
any Time Slots that are not used in the Wide Area PPP Time Slot configuration window
are used by the device connected to the DI interface.
The interface numbers available in the pull-down menu are assigned in the Wide Area
NOTE
T1, E1, and DI configuration windows. Selecting the Add Interface button or the
Delete Interface button allows available interface numbers to be added or deleted
from each pull-down menu.
Once the Wide Area PPP Time Slot configuration is complete, click on the Next>> button, and go
to the Bridging and Routing Configuration
62 CSX200 Family User's Guide
window.
