Figure 66 shows a sample Time Slot configuration for three sites. Of the 24 Time Slots, Site #1
uses 16 to communicate with Site #2 and the remaining 8 to communicate with Site #3. This
configuration varies tremendously depending on how the service provider maps out the T1 Time
Slots. Your service provider will tell you which Time Slots are active.
01-08
09-16
17-24
Site #1 is using the full T1, so all the Time Slots must have an Interface assignment. Site #2 and
Site #3 use only a fraction of the T1, but the total quantity of Time Slots must match those of Site
#1. Unused Time Slots receive an Interface number of 000.
The Interface numbers of Site #1, Site #2 and Site #3 do not have to match. Only the
NOTE
quantity of Time Slots must match (the service provider assigns the Time Slots).
005 005 005 005 005 005 005
005 005 005 005 005 005 005
006 006
006 006 006 006 006
SITE #1
Figure 66 Sample Time Slot Configuration
WAN Configuration Using Local Management
005 005 005 005
01-08
09-16 005 005 005 005
17-24 000 000 000 000
005
SITE #2
005
006 01-08 006 006 006 006
09-16 000 000 000 000
000 000 000 000
17-24
SITE #3
CSX200 Family User's Guide 139
005 005 005 005
005 005 005 005
000 000 000 000
006 006 006 006
000 000 000 000
000 000 000 000
