WPIM-DDS
This section provides Cabletron Systems part number and connector specifications for the
WPIM-DDS interface cable. The WPIM-DDS has one RJ45 port for a direct connection to a single
Digital Data Service (DDS) circuit.
Table 40
provides cable and interface type, and part number information for the WPIM-DDS
interface cable, and
Table 41
cable.
.
provides network Pin Assignment information for the DDS interface
Table 40 DDS Interface Cable Part Number
Cable and Interface Type
DDS
Table 41 Network Pinout Assignments
PIN
SIGNAL
1
Transmit Ring
2
Transmit Tip
3
Not Used
4
Not Used
5
Not Used
6
Not Used
7
Receive Tip
8
Receive Ring
WPIM Cable Specifications
Part Number
9360119
CSX200 Family User's Guide 223
