WAN Configuration Using Local Management
WAN Interface Configuration Screen Fields
The following sections describe WAN Interface Configuration screen fields.
Interface Number —
Numbers you assigned to the Time Slots on the WAN Physical Configuration screen.
User-configured field that displays the maximum packet size that can be
Max Xmit Unit —
transmitted on the selected interface. The default settings for this field are 8191 for PPP and 4095
for Frame Relay.
Displays the Line Coding for Time Slots associated with this interface. This field
Line Coding —
displays JBZS, INV-HDLC, or None. The default setting for this field is NONE.
Active Protocol —
(Frame Relay), or PPP (Point-to-Point). The default setting is NONE.
If you select PPP, the following fields display:
PPP Type:
CCP Enable:
CCP Status:
Comp Ratio:
data.
154 CSX200 Family User's Guide
Displays active Interface Numbers. Use this field to configure the Interface
Displays the active OSI Layer protocol. This field displays NONE, FR
Select BNCP from this field.
This field toggles between ON and OFF.
This field displays the status of the WAN compression.
This field displays the ratio of uncompressed to compressed transmitted
