Page 1 Local Management User’s Guide Version 2.01.XX Firmware (speciﬁed products only) WAN Products affected by this manual: CSX400 CSX400-DC CSX500 9032672-03 WAN Series HSIM-W6 HSIM-W84...
Page 3: Fcc Notice
Only qualiﬁed personnel should perform installation procedures. NOTICE Cabletron Systems reserves the right to make changes in speciﬁcations and other information contained in this document without prior notice. The reader should in all cases consult Cabletron Systems to determine whether any such changes have been made. The hardware, ﬁrmware, or software described in this manual is subject to change without notice.
Page 4: Industry Canada Notice
Notice INDUSTRY CANADA NOTICE This digital apparatus does not exceed the Class A limits for radio noise emissions from digital apparatus set out in the Radio Interference Regulations of the Canadian Department of Communications. Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites applicables aux appareils numériques de la class A prescrites dans le Règlement sur le brouillage radioélectrique édicté...
Page 5 IMPORTANT: THIS LICENSE APPLIES FOR USE OF PRODUCT IN THE FOLLOWING GEOGRAPHICAL REGIONS: CANADA MEXICO CENTRAL AMERICA SOUTH AMERICA BEFORE OPENING OR UTILIZING THE ENCLOSED PRODUCT, CAREFULLY READ THIS LICENSE AGREEMENT. This document is an agreement (“Agreement”) between You, the end user, and Cabletron Systems, Inc. (“Cabletron”) that sets forth your rights and obligations with respect to the Cabletron software program (“Program”) in the package.
Page 6 Notice UNITED STATES GOVERNMENT RESTRICTED RIGHTS. The enclosed Product (i) was developed solely at private expense; (ii) contains “restricted computer software” submitted with restricted rights in accordance with section 52.227-19 (a) through (d) of the Commercial Computer Software-Restricted Rights Clause and its successors, and (iii) in all respects is proprietary data belonging to Cabletron and/or its suppliers.
Page 7 EXPORT REQUIREMENTS. You understand that Cabletron and its Affiliates are subject to regulation by agencies of the U.S. Government, including the U.S. Department of Commerce, which prohibit export or diversion of certain technical products to certain countries, unless a license to export the product is obtained from the U.S. Government or an exception from obtaining such license may be relied upon by the exporting party.
Page 8 Notice IMPORTANT: THIS LICENSE APPLIES FOR THE USE OF THE PRODUCT IN THE FOLLOWING GEOGRAPHICAL REGIONS: EUROPE MIDDLE EAST AFRICA ASIA AUSTRALIA PACIFIC RIM BEFORE OPENING OR UTILIZING THE ENCLOSED PRODUCT, CAREFULLY READ THIS LICENSE AGREEMENT. This document is an agreement (“Agreement”) between You, the end user, and Cabletron Systems Limited (“Cabletron”) that sets forth your rights and obligations with respect to the Cabletron software program (“Program”) in the package.
Page 9 thereof, if such foreign produced direct product is subject to national security controls as identiﬁed on the U.S. Commerce Control List or is subject to State Department controls under the U.S. Munitions List. UNITED STATES GOVERNMENT RESTRICTED RIGHTS. The enclosed Product (i) was developed solely at private expense;...
Page 10 Notice Application of Council Directive(s): Manufacturer’s Name: Manufacturer’s Address: European Representative Name: European Representative Address: Conformance to Directive(s)/Product Standards: Equipment Type/Environment: We the undersigned, hereby declare, under our sole responsibility, that the equipment packaged with this notice conforms to the above directives.
Page 11: Table Of Contents
CHAPTER 1 LOCAL MANAGEMENT Chapter Organization ...1-2 WAN Features ...1-3 WAN Protocols ...1-3 ISDN ...1-3 ISDN Call Backup ...1-3 Call Backup Topology ...1-4 Spoofing ...1-5 Local Management Overview ...1-5 Management Agent ...1-5 Local vs. Remote Management ...1-5 Local Management Screen Elements...1-6 Local Management Keyboard Conventions ...1-8 Terminal Emulation Setup...1-9 Navigating Within Local Management Screens ...1-10...
Page 12 Bridge Setup Screen Fields ...1-29 Selecting a Spanning Tree Protocol...1-30 Selecting the Bridge Port Administrative Status ...1-30 Selecting the Bridge Port Pair Administrative Status ...1-31 Router Setup Screen ...1-32 Router Setup Fields ...1-32 IP Configuration Screen...1-33 IP Configuration Screen Fields...1-33 IP General Configuration Screen...1-34...
Page 13 CHAPTER 2 WAN CONFIGURATION Chapter Organization ...2-1 The WAN Physical Configuration Screen ...2-2 WAN Physical Configuration Screen Fields ...2-3 HDSL Line Configuration Fields ...2-4 T1 Line Configuration Fields...2-5 DDS Line Configuration Fields ...2-6 WPIM Timeslot Configuration Table ...2-8 WAN Interface Configuration Screen ...2-10 WAN Interface Configuration Screen Fields...2-10 Command and Interface Table Fields ...2-11 Frame Relay as the Protocol Manager ...2-12...
Page 14 Contents Configuration: Call Backup ...2-34 Configure Primary Lines and Routing ...2-36 Select the Protocol...2-36 Enable Compression Control Protocol (CCP) ...2-38 Configure Backup ...2-39 Set Idle Timeouts ...2-40 Configure the D Channel ...2-41 Set Phone Numbers and SPIDs for the Port...2-41 Set Maximum Number of Neighbor/Remote Profiles...2-42 Configure the Profiles...2-42 Verify Status ...2-42...
Page 15 APPENDIX A WPIM-SY CONFIGURATION THE WAN PHYSICAL CONFIGURATION SCREEN ... A-1 WPIM-SY Physical Configuration Fields... A-2 WAN Interface Configuration Screen Fields ... A-3 PPP CONFIGURATION ... A-4 WPIM-SY Physical Configuration ... A-4 WPIM-SY Interface Configuration... A-5 FRAME RELAY CONFIGURATION ... A-6 WPIM-SY Physical Configuration ...
Page 16 Contents APPENDIX C WPIM-DI CONFIGURATION The WAN Physical Configuration Screen ... C-1 WPIM-DI Line Configuration Fields ... C-1 The WAN Interface Configuration Screen ... C-5 WPIM-DI Configuration ... C-6 WPIM-DI Physical Configuration ... C-6 WPIM-DI Interface Configuration ... C-8 APPENDIX D MODEM SETTINGS FOR RS-232 DIAL-UP PPP BACKUP FastPro-II Modem Configuration...
Page 17: Local Management
Local Management This manual covers Local Management conﬁguration of the CyberSWITCH CSX400, CSX400-DC, and CSX500; and HSIM-W6 and HSIM-W84, as these devices share common component interfaces. This manual covers version 02.01.XX or greater, until superseded by a later version manual. For devices running version 01.XX.XX, please refer to the previous manual, part number 9032672-02.
Page 18: Chapter Organization
CyberSWITCH. Bridge Setup Screen describes how to conﬁgure an HSIM or CyberSWITCH for bridge functions. Router Setup Screen describes how to conﬁgure an HSIM or CyberSWITCH for bridge functions. IP Configuration Screen describes how to conﬁgure an HSIM or CyberSWITCH for IP routing functions.
Page 19: Wan Features
WAN Features WAN Features Some of the WAN features are listed and explained here, while others can be found in the QuickSET Conﬁguration Guide, which can be found on the QuickSET CD, or on the Cabletron Systems web site for the manuals. WAN Protocols The HSIM or CyberSWITCH interface supports ISDN BRI, which encapsulates PPP.
Page 20: Call Backup Topology
Local Management The following are reasons to use ISDN call backup: • Hardware failure of a nailed-up PPP connection • line failure Use call backup if either of the following conditions exist when using Frame Relay: • DLCI circuit fails to connect in a predetermined amount of time. •...
Page 21: Spoofing
Spooﬁng The concept of mimicking correct responses to keep level requests alive at the local end of a temporarily broken connection is called connection (or call) spooﬁng. Call spooﬁng saves connect time charges by allowing the call to be disconnected without causing the NOS to time-out the client/host connection.
Page 22: Local Management Screen Elements
Local Management Local Management Screen Elements There are ﬁve basic ﬁeld elements, as shown in the Local Management screen in EVENT MESSAGE FIELD <host name> Local Management Reboot After Download: Last Image Server IP: Last Image File Name: Download Server IP: Download File Name: EXECUTE Figure 1-1 Sample Local Management Screen...
Page 23 The following list explains each of the basic Local Management screen ﬁelds: This ﬁeld displays messages that indicate if a Local Management Event Message Field — procedure was executed correctly or incorrectly, that changes were saved or not saved to Non-Volatile Random Access Memory (NVRAM), or that a user did not have access privileges to an application.
Page 24: Local Management Keyboard Conventions
Local Management Local Management Keyboard Conventions All key names in this manual display as capital letters. For example, the ENTER key displays as ENTER, the Escape key displays as ESC, and the Backspace key displays as BACKSPACE. Table 1-3 explains the keyboard conventions used in this manual as well as the key functions. Function These selection keys perform the same Local Management function.
Page 25: Terminal Emulation Setup
Local Management Overview Terminal Emulation Setup You can use QuickSET to initiate a TELNET session if you have no other TELNET application. Your PC’s arrow keys are used extensively to navigate within TELNET screens. In order to use the arrow keys effectively for navigating within Local Management screens, you must set your PC up to emulate a Digital Equipment Corporation VT52 terminal.
Page 26: Navigating Within Local Management Screens
Local Management Navigating Within Local Management Screens To navigate within a Local Management screen, use the arrow keys of the terminal or the workstation providing terminal emulation services. The Local Management screen cursor responds to the LEFT-ARROW, RIGHT-ARROW, UP-ARROW, and DOWN-ARROW keys. Each time you press an arrow key, the Local Management screen cursor moves to the next available ﬁeld in the direction of the arrow key.
Page 27: Establishing A Telnet Connection
Figure 1-3 Hierarchy of Local Management Screens Local Management User’s Guide System Level SNMP Community Names SNMP Traps Flash Download WAN Setup Bridge Setup Router Setup Local Management Overview IP General Config IP RIP IP OSPF IPX General Config IPX SAP IPX RIP...
Page 28: Accessing Local Management
Local Management Accessing Local Management This section explains how to access and use the Local Management menu screens. Menu screens provide a path to the setup screens and status screens. Using the Menu Screens Once you have accessed the HSIM or CyberSWITCH through a TELNET connection, the Password screen, shown in Figure Type in your password and press ENTER.
Page 29: Main Menu Screen
• If you enter a valid password, the associated access level displays at the bottom of the screen and the Main Menu screen, shown in • If you enter an invalid password, the cursor returns to the beginning of the password entry ﬁeld. •...
Page 30 SNMP TRAPS FLASH DOWNLOAD FLASH DOWNLOAD WAN SETUP WAN SETUP BRIDGE SETUP BRIDGE SETUP ROUTER SETUP ROUTER SETUP Figure 1-6 Setup Menu Screen The SNMP Community Names screen allows you to change or — Figure 1-6 shows the Flash Image Version 02.XX.XX Flash Image Version 02.XX.XX...
Page 31: System Level Screen
Router Setup — The Router Setup screen accesses two other screens that provide general IP or IPX routing conﬁguration and allow you to enable or disable the Routing Information Protocol (RIP) and the Service Advertising Protocol (SAP) features.
Page 32 Local Management Access the System Level screen to highlight the System Level option and pressing ENTER. The System Level screen displays. <host name> Local Management <host name> Local Management System Date: 03/25/1999 System Date: 03/25/1999 Host IP Address 0.0.0.0 Host IP Address Subnet Mask 255.255.0.0 Subnet Mask...
Page 33 • Set a new value for the Subnet Mask when the management workstations designated to receive SNMP traps reside on a different subnet (for example, across a gateway or router). To set a Subnet Mask, refer to Phys Address —...
Page 34: Setting The System Date
Local Management Setting the System Date The HSIM or CyberSWITCH is year 2000 compliant so that the System Date ﬁeld can be set beyond the year 1999. To set the system date, perform the following steps: Use the arrow keys to highlight the System Date field. Enter the date in an MM/DD/YYYY format.
Page 35: Setting The Host Ip Address
Setting the Host IP Address To set the host IP address, perform the following steps: Use the arrow keys to highlight the Host IP Address field. Enter the IP address using Decimal Dotted Notation (DDN) format. For example: 168.192.25.17 Press ENTER. If the IP address entered was a valid format, the cursor returns to the beginning of the Host IP Address field.
Page 36: Setting The Default Interface
Local Management Enter the IP address of the Default Gateway using DDN format. For example: 168.192.79.121 Press ENTER. If the Default Gateway address entered was a valid format, the cursor returns to the beginning of the Default Gateway field. If the entry was not valid, the Event Message field displays “INVALID DEFAULT GATEWAY OR FORMAT ENTERED”.
Page 37: Snmp Community Names Screen
SNMP Community Names Screen This section explains how to assign community names. Community names allow you to control Local Management access by establishing three passwords. Each password controls a different level of access to HSIM or CyberSWITCH Local Management. Access the SNMP Community Names screen, shown in by using the arrow keys to highlight the SNMP Community Names option and pressing ENTER.
Page 38: Setting Snmp Community Names
Local Management The following explains each of the SNMP Community Names screen ﬁelds: Displays the user-deﬁned names through which a user accesses the HSIM Community Name — or CyberSWITCH Local Management. Any community name entered here acts as a password to Local Management.
Page 39: Snmp Traps Screen
SNMP Traps Screen The SNMP Traps screen, shown in CyberSWITCH to send traps to as many as eight remote management workstations. SNMP traps are messages about network events and device operational statistics. Access the SNMP Traps screen from the Setup Menu screen by using the arrow keys to highlight the SNMP Traps option and pressing ENTER.
Page 40: Setting The Snmp Trap Destination
Local Management Setting the SNMP Trap Destination Each management workstation designated to receive SNMP traps from the HSIM or CyberSWITCH must have a valid IP address and community name. To set and enable SNMP trap destination, perform the following steps: Use the arrow keys to highlight the Trap Destination field that you want to modify.
Page 41: Flash Download Screen
Flash Download Screen The Flash Download screen (Figure server to the HSIM or CyberSWITCH. Access the Flash Download screen from the Setup Menu screen by using the arrow keys to highlight the Flash Download option and pressing ENTER. The Flash Download screen, shown in Figure 1-10, displays.
Page 42: Selecting A Flash Download Method
Local Management The following deﬁnitions explain each of the Flash Download screen ﬁelds. Use this ﬁeld to select the method you wish to use to download the Download Method — ﬁrmware image to the HSIM or CyberSWITCH. • Reboot After Download — chosen.
Page 43 RUNTIME Download If you select RUNTIME Download, perform the following steps: Use the arrow keys to highlight the Reboot After Download field. Press the SPACE bar or BACKSPACE to select one of the following: • YES, if you want the HSIM or CyberSWITCH to reboot and use the new ﬁrmware image immediately.
Page 44 Local Management BOOTPROM Download If you select a BOOTPROM Download, perform the following steps: Use the arrow keys to highlight the Commit to Flash field. Press the SPACE bar or BACKSPACE to select one of the following: • YES, if you want the HSIM or CyberSWITCH to continue using the existing ﬁrmware image without interrupting network operation.
Page 45: Bridge Setup Screen
Bridge Setup Screen The Bridge Setup screen enables you to select a Spanning Tree protocol and enable/disable bridge ports. Access the Bridge Setup screen, shown in the Bridge Setup option and pressing ENTER. The Bridge Setup screen displays. <host name> Local Management SPANNING TREE PROTOCOL: BRIDGE PORT ADMIN STATUS: BRIDGE PORT PAIR ADMIN STATUS:...
Page 46: Selecting A Spanning Tree Protocol
Local Management Selecting a Spanning Tree Protocol To select the Spanning Tree protocol to be used by the HSIM or CyberSWITCH, perform the following steps: Use the arrow keys to highlight the SPANNING TREE PROTOCOL field. Press the SPACE bar or BACKSPACE to select [IEEE 802.1], [DEC], or [NONE]. Use the arrow keys to highlight the SAVE command field.
Page 47: Selecting The Bridge Port Pair Administrative Status
Selecting the Bridge Port Pair Administrative Status To select the bridge port pair administrative status, perform the following steps: Use the arrow keys to highlight the [BRIDGE_PORT XX] field at the bottom of the Bridge Setup screen. Press the SPACE bar or BACKSPACE to select the bridge port you want to configure. The selected bridge port displays in the Bridge Port Pair Admin Status field.
Page 48: Router Setup Screen
Local Management Router Setup Screen The Router Setup menu screen allows you to choose either IP or IPX routing for your HSIM or CyberSWITCH. Access the Router Setup screen, shown in ROUTER SETUP menu item in the Setup Menu and pressing ENTER. The Router Setup menu screen displays.
Page 49: Ip Configuration Screen
HSIM or CyberSWITCH for IP Routing and enable RIP on the HSIM or CyberSWITCH. Access the IP Conﬁguration menu screen, shown in highlight the IP menu item on the Router Setup screen and pressing ENTER. The IP Conﬁguration screen displays. <host name> Local Management IP Conﬁguration Screen Fields...
Page 50: Router Name
Displays the status of IP Routing. Status — UpTime — Displays the amount of time elapsed since the last time the HSIM or CyberSWITCH was rebooted. 1-34 IP Router ID: XXX.XXX.XXX.XXX IP Router ID: XXX.XXX.XXX.XXX IP GENERAL CONFIGURATION IP GENERAL CONFIGURATION Status: Enabled Status: Enabled...
Page 51: Ip General Configuration Fields
+PORT- — +REDIRECTOR- — Use this ﬁeld to toggle through a list of commonly used UDP port numbers. UDP port numbers are associated with the relay agent functionality of the router. User Datagram Protocol (UDP) Port affected. UDP Port —...
Page 52 On each port, Frame Type speciﬁes the format of the frame in which IP packets are encapsulated for transmission. The Frame Type options available for each router port are dependent on the type of media supported by that router port. The choices are: Ethernet, SNAP, i8022, Novell, Localtalk, Native-wan, Encap-enet, Encap-enet-8022, Encap-enet-snap, Encap-enet-novell, Encap-tokenring-8022, Encap-tokenring-snap, Encap-fddi-8022, Encap-fddi-snap, Other.
Page 53 IP routing on any port without losing your conﬁguration, or you can temporarily switch from IP routing back to bridging. To enable IP Routing Services on a router port, complete the following steps: Use the arrow keys to highlight the IP Routing option under Port Level Setup.
Page 54 Local Management Enabling IP Forwarding on a Port By default, IP Forwarding is disabled on each router port. Your device cannot begin forwarding IP data packets on any router port until you enable IP Forwarding on that port. To enable IP Forwarding on a router port, complete the following steps: Use the arrow keys to highlight the IP Forwarding option.
Page 55 However, because each subnet constitutes a separate broadcast domain and LAN broadcasts are not forwarded across routers, ARP does not work beyond a host’s local network or subnetwork. One of the primary purposes of a router is to conﬁne LAN broadcast trafﬁc to each local network or subnetwork.
Page 56: Ip Rip
An entry exists in the IP Forwarding Table for the destination host’s network. Enabling Proxy ARP on a router port allows IP hosts to dynamically obtain the MAC-layer address of other IP hosts attached to different networks or subnetworks by using broadcast ARP request packets.
Page 57 Entries in RIP-2 routing tables always have a Next Hop ﬁeld. The Next Hop is the IPv6address of the next router along the path to the destination. The purpose of the Next Hop in the routing table is to prevent packets from being routed through extra hops in the system. The limitation of a maximum network diameter of 15 hops for the Next Hop ﬁeld is common to both...
Page 58 RIP is intended to allow routers to exchange information for computing routes through an IPv6-based network. Any router that uses RIP is assumed to have interfaces to one or more networks, otherwise it isn’t a router. These are referred to as directly connected networks.
Page 59 If the router is not conﬁgured to authenticate RIP-2 messages, then RIP-1 and unauthenticated RIP-2 messages will be accepted. Authenticated RIP-2 messages will be discarded. If the router is conﬁgured to authenticate RIP-2 messages, then RIP-1 messages and RIP-2 messages which pass authentication testing will be accepted.
Page 60 Use the arrow keys to highlight the SAVE command field at the bottom of the screen, and then press ENTER. The message “SAVED OK” displays. Exit back out to the Router Setup screen, use the arrow keys to highlight the INITIALIZE command, and use the ENTER key to initialize the device. The connection to Local Management will disconnect and re-entry is necessary for any further configuration.
Page 61: Ip Ospf Configuration
Use the ENTER key to toggle the entry. RIP1 is the default, the other choices are RIP2, DON’T SEND, and RIP1 COMPATIBLE. Make the proper selection for your network. Use the arrow keys to highlight the RIP receive info option. Use the ENTER key to toggle the entry.
Page 62 Figure 1-16 IP OSPF Conﬁguration Screen To enable OSPF complete the following steps: From the Router Select screen, select IP and press ENTER. The IP Configuration screen displays. From the IP Configuration screen, use the arrow keys to select IP OSPF. Press ENTER, and the IP OSPF Configuration screen shown in Use the arrow keys to select OSPF: Disabled.
Page 63 Hello packets sent out of this interface. When you have finished use the arrow keys to select Poll Interval. Type the number of seconds that you wish to use for Poll Interval. If a neighboring router has become inactive (Hello packets have not been sent for [router dead] seconds, it may be necessary to send Hello packets to the dead neighbor.
Page 64: Ipx Configuration Screen
SAP screens to conﬁgure the HSIM or CyberSWITCH for IPX Routing and enable RIP routing or Source Advertisement Protocol (SAP) routing on the HSIM or CyberSWITCH. Access the IPX Conﬁguration screen, shown in the IPX menu item on the Router Setup and pressing ENTER. The IPX Conﬁguration screen displays. <host name> Local Management IPX Conﬁguration Fields...
Page 65: Ipx General Configuration Screen
To access the IPX General Conﬁguration screen, use the arrow keys to highlight the IPX General Config menu item and press ENTER. The IPX General Conﬁguration screen shown in Figure 1-18 displays. <host name> Local Management <host name> Local Management Router Name: IPX Version: XX.XX.XX Router Name: IPX Version: XX.XX.XX IPX Routing: ENABLED Port: 1...
Page 66: Ipx General Configuration Fields
Selecting a Port for Conﬁguration Routing Services allows you to choose the ports that you want to conﬁgure for IPX routing. To select a router port to conﬁgure for IPX routing, complete the following steps: Use the arrow keys to highlight the PORT option.
Page 67 On each port, Frame Type speciﬁes the format of the frame in which IPX packets are encapsulated for transmission. The Frame Type options available for each router port are dependent on the type of media supported by that router port. Select the Frame Type based on your implementation, such as Encap-enet for bridging and Native-wan for routing.
Page 68 ENTER. The message “SAVED OK” displays. Enabling IPX Forwarding on a Port By default, IPX Forwarding is disabled on each router port. Your device cannot begin forwarding IPX data packets on any router port until you enable IPX Forwarding on that port.
Page 69: Ipx Routing Over Frame Relay
The Network is the IPX Network number associated with the Frame Relay network. Network — The Node is the MAC address of the remote router on the other end of the WAN link. Node — Circuit ID — The Circuit ID is the DLCI identifying the virtual circuit connection to the Telco.
Page 70: Enabling The Ipx Sap Routing Protocol On A Port
Each router running IPX SAP gathers this LAN based information from the locally connected network segments and adds it to its Service Advertisement Table. Each table contains the Novell Network Number and type of services available on all Novell servers known to the IPX SAP.
Page 71: Enabling Rip On A Port
IPX packets. The ability to switch RIP on and off on a port-by-port basis provides great ﬂexibility. On the same device, some router ports can be running RIP while other router ports are not. If necessary, you can temporarily disable RIP on any port without affecting the rest of your conﬁguration.
Page 72 Use the ENTER key to toggle the entry to ENABLED. Use the arrow keys to highlight the SAVE command field at the bottom of the screen, and then press ENTER. The message “SAVED OK” displays. 1-56 IPX Router ID: 0.0.0.0 IPX RIP CONFIGURATION System Level RIP: Port Level RIP: SAVE Figure 1-21 IPX RIP Conﬁguration Screen...
Page 73: Wan Configuration
WAN CONFIGURATION This chapter explains how to conﬁgure the HSIM or CyberSWITCH through Local Management for WAN service. The WAN Setup menu item accesses screens which allow you to conﬁgure the HSIM or CyberSWITCH for a WAN Physical Interface Module (WPIM). Refer to the host platform User’s Guide for instructions about how to set up and access Local Management.
Page 74: The Wan Physical Configuration Screen
WAN Configuration The WAN Physical Conﬁguration Screen To access the WAN Physical Conﬁguration screen, use the arrow keys to highlight the WAN SETUP menu item, then press ENTER. The screen shown in When there is more than one WPIM installed into the host platform, information for NOTE the second WPIM will display next to WPIM 1.
Page 75: Wan Physical Configuration Screen Fields
WAN Physical Conﬁguration Screen Fields The following sections describe WAN Physical Conﬁguration screen ﬁelds and provide instructions for setting them. The WAN Physical Conﬁguration screen lets you conﬁgure the WPIM or “Physical Interface.” To select the WPIM you wish to conﬁgure, proceed as follows: Use the arrow keys to highlight the WPIM X command field at the bottom of the screen.
Page 76: Hdsl Line Configuration Fields
WAN Configuration WAN INT CONFIG (Command) — the WAN Interface Conﬁguration screen displays. Refer to the Screen section. REMOTE SETUP (Command) — Returns user to the previous screen in the hierarchy. RETURN (Command) — HDSL Line Conﬁguration Fields HDSL Tx Clock Source — ﬁeld toggle between Loop-Timing (Extracted Line Data) and Local-Timing (Internal Clock).
Page 77: T1 Line Configuration Fields
T1 Line Conﬁguration Fields The conﬁguration ﬁelds displayed on the WAN Physical Conﬁguration screen shown in Figure 2-3 are speciﬁc to the T1 mode of the HSIM or CyberSWITCH. The service provider (i.e., AT&T, Sprint, MCI, Bell Atlantic, etc.) determines the NOTE settings for the following ﬁelds.
Page 78: Dds Line Configuration Fields
WAN Configuration T1 Loopback (Selectable) — and allows the user to isolate faults. The selections for this ﬁeld are None, Line-Loop, and Payload-Loop. In Line-Loop the entire T-1 line is looped back, including the framing bits, CRC, and the facility data link. This happens before the framer. In Payload-Loop, only the 24 time slots are looped back, which happens behind the framer, and does not include the framing bits, CRC, and facility data link.
Page 79 The WAN Physical Configuration Screen Displays the DDS Line Mode. The selections toggle between DDS Line Mode (Toggle) — DDS-PRI (primary) and DDS-CC (clear channel). This ﬁeld should be set according to information from the service provider. The default setting for this ﬁeld is DDS-PRI. DDS Tx Clock Source (Toggle) —...
Page 80: Wpim Timeslot Configuration Table
WAN Configuration WPIM Timeslot Conﬁguration Table The WPIM Timeslot Conﬁguration table allows the user to conﬁgure the way in which the Cabletron Systems WAN module uses the T1 line. The conﬁguration table consists of 24 timeslots. Each timeslot must be assigned an Interface number (for example, 002 for an active Interface number or 000 if the timeslot is not used).
Page 81 SITE #1 24 Timeslots Figure 2-5 shows a sample conﬁguration for three sites. Of the 24 timeslots, Site #1 uses 16 to communicate with Site #2 and the remaining 8 to communicate with Site #3. This conﬁguration varies tremendously depending on how the service provider maps out the T1 timeslots. The service provider indicates which timeslots are active.
Page 82: Wan Interface Configuration Screen
WAN Configuration WAN Interface Conﬁguration Screen This section describes the features of the WAN Interface Conﬁguration screen. Access the screen by using the arrow keys to highlight the WAN INT CONFIG command ﬁeld at the bottom of the WAN Physical Conﬁguration screen, then press ENTER. The WAN Interface Conﬁguration screen displays, as shown in Figure <host name>...
Page 83: Command And Interface Table Fields
ProtMgrIface (Selectable) — the case of Frame Relay the Protocol Manager assigned to the FR link is automatically selected. This allows for mapping FR DLCI(s) when the interface number ﬁeld has a 000 typed into it. Type the DLCI address into the DLCI address ﬁeld. Press the SPACE bar to display “Inactive” in the Circuit State ﬁeld, and then SAVE these changes.
Page 84: Frame Relay As The Protocol Manager
WAN Configuration Frame Relay as the Protocol Manager Refer to Figure 2-3 for the following parameters displayed for FR. In FR PToMP mode, DLCI’s can be learned dynamically and do not need to be NOTE entered in the screen. Once a DLCI is entered, it becomes a “statically” entered DLCI. To remove a statically-entered DLCI, enter the IF# of the DLCI (see the Interface Screen), then enter “Invalid”...
Page 85: Ppp As The Protocol Manager
PPP as the Protocol Manager <host name> Local Management Interface Number: Max Xmit Unit: ProtMgrIface: Active Protocol: PPP MRU: ECP Enable: ECP Status: CCP Enable: CCP Status: Comp Ratio: PORTS: SAVE [1-32] Figure 2-7 WAN Interface Conﬁguration Screen (PPP) Refer to Figure 2-7 for the following parameters displayed for PPP.
Page 86: Remote Profiles Setup
WAN Configuration Remote Proﬁles Setup To access the Remote Proﬁles Setup screen from the WAN Physical Conﬁguration screen, use the arrow keys to highlight the Remote Setup option, then press ENTER. The screen shown in Figure 2-8 displays. CSX400 Local Management REMOTE PROFILES SETUP REMOTE PROFILE CONFIGURATION Profile Number...
Page 87 Remote Profiles Setup The ﬁelds in the Remote Proﬁles Selection(s) are deﬁned as follows: Interface number of the proﬁle. IF# — Name — The name of the proﬁle as deﬁned by the user. Remote Identiﬁer. RID — Proﬁle number, the information used to describe a possible connection. PF # —...
Page 88: Bandwidth-On-Demand (Multilink Protocol) Configuration
WAN Configuration Bandwidth-on-Demand (Multilink Protocol) Conﬁguration To access the Bandwidth-on-Demand Conﬁguration screen from the Remote Proﬁles Setup screen, use the arrow keys to highlight the BoD Configuration option, then press ENTER. The screen shown in Figure 2-9 displays. The screen is laid out with the parameter name in the left column, the min-max settings in the second column, and the modiﬁable display ﬁeld in the third column.
Page 89 Bandwidth-on-Demand (Multilink Protocol) Configuration The ﬁelds for the BoD feature are described as follows: Speciﬁes whether or not MP support is desired. To Bandwidth-on-Demand (BoD) option — successfully negotiate MP, both devices must support MP. The default setting is DISABLE. Line Utilization (LU) Threshold (LUT)% —...
Page 90: Configuration: Full T1 Configuration Using Ppp
WAN Configuration Either side controls Bandwidth — by either side, i.e., both parties. Normally only the caller controls the bandwidth. The default setting is DISABLE. Conﬁguration: Full T1 Conﬁguration Using PPP This section provides step-by-step instructions for conﬁguring the HSIM or CyberSWITCH to use a full T1 circuit in a PPP environment.
Page 91: T1 Physical Configuration
T1 Physical Conﬁguration Begin the T1 conﬁguration by accessing the WAN Physical Conﬁguration screen through Local Management (Figure 2-3). Access the WAN Physical Conﬁguration screen from the WAN SETUP menu item in the host platform. Proceed with the following steps: Use the arrow keys to highlight the [WPIM X] field at the bottom of the screen.
Page 92: T1 Interface Configuration
WAN Configuration If you are using a Local clock source, set only one end of the circuit for Local, and the other end must be set for Loop. CAUTION Use the arrow keys to highlight T1 Line Buildout (LBO). Press the SPACE bar to select 0 dB unless the service provider recommends another setting, then press ENTER.
Page 93: Configuration: Fractional T1 Configuration Using Ppp
Conﬁguration: Fractional T1 Conﬁguration Using PPP This section provides step-by-step instructions for conﬁguring the HSIM or CyberSWITCH to use a fractional T1 circuit in a PPP environment. This example assumes the setup shown in Figure 2-11 using two CSX400s with each containing a HSIM or CyberSWITCH. Conﬁgurations may vary depending on the host platform.
Page 94: T1 Physical Configuration
WAN Configuration T1 Physical Conﬁguration Begin the HSIM or CyberSWITCH physical conﬁguration by accessing the WAN Physical Conﬁguration screen through Local Management Proceed with the following steps: Use the arrow keys to highlight the [WPIM X] field at the bottom of the screen. Press the SPACE bar to select the number of the WPIM being configured, then press ENTER.
Page 95: T1 Interface Configuration
Use the arrow keys to highlight T1 Tx Clock Source. Use the SPACE bar to select Local (no clock source provided by telephone company) or Loop (clock source provided by telephone company), then press ENTER. If you are using a Local clock source, set only one end of the circuit for Local, the other end must be set for Loop.
Page 96: Configuration: Frame Relay
WAN Configuration Conﬁguration: Frame Relay This section provides step-by-step instructions for conﬁguring the HSIM or CyberSWITCH to use a T1 circuit in a Frame Relay environment. This example assumes the setup shown in using two CSX400s, each with an HSIM or CyberSWITCH installed. Conﬁgurations may vary depending on the host platform.
Page 97: Frame Relay Physical Configuration
Frame Relay Physical Conﬁguration Begin the HSIM or CyberSWITCH physical conﬁguration by accessing the WAN Physical Conﬁguration screen through Local Management Use the arrow keys to highlight the [WPIM X] field at the bottom of the screen. Press the SPACE bar to select the number of the WPIM to be configured, then press ENTER. Use the arrow keys to highlight the MgrType field.
Page 98 WAN Configuration Point to MultiPoint Conﬁguration (LM WAN Interface Conﬁguration) LMI Type If the LMI type required is ANSI T1-617 Annex D version 1994, no more configuration is needed. It is recommended that the box be reset after the DLCIs are known by the HSIM or CyberSWITCH.
Page 99 Point To Point Mode (LM WAN Interface Conﬁguration) The difference in conﬁguration between PtoP and PtoMP is that DLCIs are not learned dynamically. DLCI information must be entered in statically, even if in an LMI mode. All the other information in FR PtoMP conﬁguration is applicable. Since in Point To Point mode the DLCI is static, it will not be deleted if the switch sends no information on the DLCI, but must be deleted manually through LM or SNMP, nor will DLCIs be added dynamically.
Page 100: Frame Relay Interface Configuration
WAN Configuration Use the arrow keys to highlight T1 Line Buildout (LBO). Press the SPACE bar to select to 0 dB unless the service provider recommends another setting, then press ENTER. Use the arrow keys to highlight the SAVE command, then press ENTER. The message “SAVE DONE!”...
Page 101: Configuration: Dds Service
In FR PtoMP, there is an option to statically enter the DLCIs in association with a Protocol Manager, the physical port and MIB II, using the DLCI ﬁeld in the Interface screen. If the DLCI is not static, it will be deleted if the Frame Relay switch determines that the DLCI has been eliminated.
Page 102: Dds Service Physical Configuration
WAN Configuration The line conﬁguration information shown in Conﬁguration Information Required By User Clock Source Line Mode FR-LMP (Frame Relay Only) DDS Service Physical Conﬁguration Begin the DDS conﬁguration by accessing the WAN Physical Conﬁguration screen through Local Management. To access the WAN Physical Conﬁguration screen, use the arrow keys to highlight the WAN Setup option, then press ENTER.
Page 103: Dds Service Interface Configuration
Proceed with the following steps: Use the arrow keys to highlight the WPIM X field at the bottom of the screen. Press the SPACE bar to select the number of the WPIM being configured, then press ENTER. Use the arrow keys to highlight MgrType, and choose the Protocol Manager from PPP, FR PtoMP, FR PtoP, or HDLC using the space bar to toggle the selections.
Page 104: Troubleshooting The Frame Relay Connection
The FR Error MIB Table, and reﬂects LMI or DLCI data errors • The Mib Navigator command “fr” A discussion of what is provided by the FR DTE bridge/router and the FR DCE switch needs to be clariﬁed: Communication with the FR switch is done through one of two methods: •...
Page 105: Fr Error Table
• Synchronous Polling Messages. The t391 timer for ANSI/ITU Frame Relay forms the basis for polling between the FR switch and the FR DTE (us). We transmit a STATUS ENQUIRY every t391 seconds (10 by default) to the FR switch. We expect a STATUS RESPONSE before we reach our next t391 polling cycle.
Page 106: Configuration: Call Backup
WAN Configuration unknownAddress: frame received on a virtual circuit which was not active or administratively disabled. dlcmiProtoErr: unspeciﬁed error occurred when attempting to interpret link maintenance frame. dlcmiUnknownlE: link maintenance frame contained an Information Element type which is not valid for the conﬁgured link maintenance protocol. dlcmiSequenceErr: link maintenance frame contained a sequence number other than the expected value.
Page 107 SITE #1 PRIMARY CSX400 #1 WPIM-T1 WPIM-S/T NT-1 BACKUP The procedures listed below and detailed in the following sections must be performed in the order given to properly conﬁgure the HSIM or CyberSWITCH for call backup: • Conﬁgure primary lines and routing. •...
Page 108: Configure Primary Lines And Routing
WAN Configuration Network Tools can be found in the MIB NAVIGATOR selection in the main menu of NOTE Local Management for the host platform. Conﬁgure Primary Lines and Routing Conﬁgure the primary lines. Refer to the appropriate WPIM user’s manual. Conﬁgure routing if used.
Page 109 Proceed with the following steps: Use the arrow keys to highlight the [WPIM X] field at the bottom of the screen. Press the SPACE bar to select the WPIM number of the HSIM or CyberSWITCH being configured, then press ENTER. Typically the backup HSIM or CyberSWITCH will be installed in slot 2 of the host platform.
Page 110: Enable Compression Control Protocol (Ccp)
WAN Configuration Enable Compression Control Protocol (CCP) The WAN Interface Conﬁguration screen, Control Protocol (CCP) feature is to be turned on (normally it is desirable to have this function on). Otherwise, the functions of this screen are not normally needed for call backup. Access the WAN Interface Conﬁguration screen by using the arrow keys to highlight the WAN Int Conﬁg command in the WAN Physical Conﬁguration screen, then press ENTER.
Page 111: Configure Backup
The commands in the rest of the procedure are Network Tools commands. Refer to NOTE the host platform manual for detailed information on accessing Network Tools. Conﬁgure Backup Backup is normally used to conﬁgure a backup connection if a primary connection fails. It can also be used to reduce CPU time for an unused interface.
Page 112: Set Idle Timeouts
WAN Configuration Example 1: There is a nailed-up PPP interface #3, and to back it up, ISDN interface #4 is used with the default values. Use the command: setbackup 3 4 Example 2: For any switched medium like ISDN there are two types of interfaces, primary and secondary (backup).
Page 113: Configure The D Channel
Configuration: Call Backup Conﬁgure the D Channel Use the following command in Network Tools to set the switch type: setswitchtype [WANPORTNUM] [SWITCHTYPE] If the HSIM or CyberSWITCH occupies WAN port number one, use 1, if it WANPORTNUM — occupies port number two, use 2 as the WANPORTNUM. SWITCHTYPE —...
Page 114: Set Maximum Number Of Neighbor/Remote Profiles
WAN Configuration Set Maximum Number of Neighbor/Remote Proﬁles A neighbor/remote proﬁle describes a possible connection. The maximum should be set to account for support of PPP Multilink. If PPP Multilink is used, then the number of proﬁles must accommodate the maximum possible number of additional “more BW” connections/calls desired. Consequently, each neighbor proﬁle would then describe a possible connection to the same remote end point (user).
Page 115: Reset
Configuration: Call Backup Use the Network Tools commands ct and dt to test the line by doing a manual connect or disconnect: connects (places) a call for the interface designated. ct [IFACENUM] disconnects (hangs up) the call. dt [IFACENUM] These three Network Tools commands allow the user to check whether or not the ISDN line and proﬁle(s) have been conﬁgured properly and that a connection is possible.
Page 116 WAN Configuration 2-44 Local Management User’s Guide...
Page 117: Mib Navigator
MIB Navigator This chapter explains how to use the MIB Navigator utility. The MIB Navigator allows access to a command set from which you can conﬁgure and manage your HSIM or CyberSWITCH. Chapter Organization The following list summarizes the organization of this chapter: MIB Navigator Screen –...
Page 118: Mib Navigator Screen
MIB Navigator MIB Navigator Screen Access the MIB Navigator screen from the Main Menu screen using Local Management (refer to Accessing Local Management MIB NAVIGATOR menu item, then press ENTER. At the MIB Navigator cursor, type Help and press ENTER. The MIB Navigator Help screen shown in Welcome to MIB Navigator MIBNav->...
Page 119: Mib Navigator Command Set Overview
The MIB Navigator views the MIB tree hierarchy as a directory. hierarchy. Each layer is numerically encoded, so that every branch group and leaf object in the MIB is identiﬁed by a corresponding number, known as an Object Identiﬁer (OID). This allows the MIB Navigator to navigate through the MIB and access the manageable leaf objects.
Page 120 MIB Navigator PPP Security and Spooﬁng Commands — to set up spooﬁng. The commands, detailed starting on ISDN and Backup Commands — primary and backup conﬁgurations. The commands, detailed starting on setbackup setdemandif Other commands allow you to access and manage network devices Other Commands —...
Page 121: Conventions For Mib Navigator Commands
Conventions for MIB Navigator Commands This manual uses the following conventions for denoting commands: Information keyed by the user is shown in this helvetica font. • • In the examples, information keyed in by the user is indicated by bold font. •...
Page 122: Navigation Commands
MIB Navigator Navigation Commands The following MIB Navigation commands allow you to move from MIB object to MIB object within the MIB tree. branch: Syntax: branch [path] Description: The branch command displays all of the leaves in the MIB tree below a speciﬁed path.
Page 123 ctron: Syntax: ctron Description: The ctron command allows you to change directories to the Cabletron MIB (1.3.6.1.4.1.52) without keying in the entire path. Options: Not Applicable Example: dir: Syntax: dir [- 1pdm] [PATH] Description: The dir command lists the contents of the directory sub-tree speciﬁed. If no [directory-path] is speciﬁed, the contents of the current directory are displayed.
Page 124 MIB Navigator get: Syntax: get <PATH> Description: The get command returns the value of a managed object. This is only valid for “leaf” entries in the MIB tree (or managed objects in the MIB). Options: Not Applicable Example: grep: grep <option> string Syntax: Description: Allows you to search the MIB tree for a speciﬁc character string.
Page 125 Syntax: ls [-1pdm] [PATH] Description: The ls command lists the contents of the directory sub-tree speciﬁed. If no [directory-path] is speciﬁed, the contents of the current directory are displayed. The display options are as follows: -1 Displays the OID value along with the ASCII name of the leaf object. -p Lists all the entries along with the path name of the leaf object.
Page 126 MIB Navigator next: Syntax: next [path] Description: The next command enables you to determine the next leaf in the speciﬁed path within the managed device’s MIB. Options: Not Applicable Example: pwd: Syntax: Description: The pwd command displays the full pathname for the directory in which you are currently working.
Page 127 set: Syntax: set <OID> <value> Description: The set command enables you to set the value of a managed object. This command is valid only for leaf entries in the current MIB tree, or for managed objects in the MIB. If the leaf speciﬁed does not exist for the given path, MIB Navigator asks for a value.
Page 128 MIB Navigator Syntax: su [community name] Description: The su command enables you to change your community name to allow for different access to the MIB. The community name that you enter allows you either read-only, read-write, or super-user access to that device’s MIBs, depending on the level of security access assigned the password through the SNMP Community Names screen.
Page 129 wan: Syntax: Description: The wan command will change the current directory to Cabletron Systems WAN MIB: (/1/3/6/1/4/1/52/4/1/2/7/2). Options: Not Applicable whoami: whoami Syntax: Description: The whoami command displays your community string and access privileges to the MIB. When using the whoami command, one of these three access levels displays: read-only, read-write, and super-user.
Page 130: Ppp Security Command
MIB Navigator PPP Security Command The following is a command for PPP Security. pppsecurity: Syntax: pppsecurity <iﬁndex#><CHAP><direction><username><secret> pppsecurity <iﬁndex#><PAP><direction><peerid><password> pppsecurity <iﬁndex#><NONE> Description: The pppsecurity command allows you to list and set PPP Security on an interface basis. Options: Not Applicable Example: The example below shows the syntax used to set interface 7 to CHAP enabled.
Page 131 setspoof <IF> NB20 <ON/OFF> setspoof <IF> SP Description:The setspoof command allows the user to enable or disable spooﬁng on all the listed packet types or on a speciﬁc packet type. Where TIME INTERVAL: T=n*30(sec), where n belongs to the domain of natural numbers (1,2,3...), set spooﬁng on a time interval basis (in seconds);...
Page 132: Isdn Configuration Commands
MIB Navigator ISDN Conﬁguration Commands The following ISDN conﬁguration commands are used to set up primary and backup conﬁgurations. setbackup: Syntax: setbackup <PRIMARYIFNUM> <BACKUPIFNUM><TIMETOCONNECT> <TIMETODISCONNECT> <CONNECTRETRIESNUM> <TIMEBETWEENCONNECTRETRIES> <BACKUPOVERRIDE> Description: The setbackup command allows you to conﬁgure backup/failover. Refer Options: Not Applicable Example: setisdnbri: setisdnbri <WANPORTNUM>...
Page 133 setswitchtype: Syntax: setswitchtype <WANPORTNUM> <SWITCHTYPE> Description: The setswitchtype command allows you to set the switch type. Options: Currently supported switch types are NI1 (BRI), ATT-5ESS (BRI/PRI), ATT-4ESS (PRI), DMS100 (BRI/PRI), and NET3 (BRI). Switch type is settable using one of the following: NI1, ATT5, ATT4, DMS100, or NET3.
Page 134 MIB Navigator setidletimeout: Syntax: setidletimeout <IFNUM> <TRANSMITIDLETIMEOUT> <RECEIVEIDLETIMEOUT> Description: The setidletimeout command allows you to set the idle time out value in seconds in which a packet needs to be transmitted/received before the interface is automatically disconnected. Options: Not Applicable Example: setalarmtime: setalarmtime <WANPORTNUM>...
Page 135 setdemandif: Syntax: setdemandif <DEMANDIFNUM> <TIMEBETWEENCONNECTRETRIES> Description: The setdemandif command allows you to set the amount of time between retries to reconnect a primary demand interface which has failed. Options: Not Applicable Example: isdnstat: isdnstat <WANPORTNUM> Syntax: isdnstat callhist Description: The isdnstat command allows you to list the ISDN settings and the Signalling channel status for a particular WANPORTNUM.
Page 136: Other Commands
MIB Navigator Other Commands The other commands listed in this section activate functions on the LM managed device or devices being accessed through MIB Navigation. arp: Syntax: arp <options> Description: The arp command provides access to the ARP (Address Resolution Protocol) cache, enabling you to view cache data, delete entries, or add a static route.
Page 137 bridge: Syntax: bridge <ENABLE/DISABLE> <IFNUM/ALL> Description: The bridge command allows management of bridging upon one or more interfaces of the device. Bridging may be enabled or disabled at your request, either one at a time or all at once. Specifying a single interface number affects the bridging status of that interface, while specifying ALL affects every interface of the device.
Page 138 MIB Navigator Example: defroute: defroute [interface number] [IP address] Syntax: Description: The defroute command allows you to set the default IP route to a managed device through the speciﬁed interface. Options: Not Applicable Example: dhcp: dhcp <options> Syntax: Description: The dhcp command provides a status of the Dynamic Host Conﬁguration Protocol feature.
Page 139 dhcp <IFNUM> <GATEWAY> <DNSADDRESS> <WINSADDRESS> <DOMAINNAME> The IFNUM is the Ethernet port number. The four conﬁguration parameters can be passed to the hosts (clients). These are the IP address of their default gateway, the IP address of their domain name server, the IP address of their WINS server, and their domain name.
Page 140 MIB Navigator ds1alarm: Syntax: ds1alarm ds1alarm -ea <WANID> ds1alarm -da <WANID> ds1alarm -er <WANID> ds1alarm -dr <WANID> ds1alarm -et <WANID> ds1alarm -dt <WANID> ds1alarm -sec <WANID> <VALUE> ds1alarm -sei <WANID> <VALUE> ds1alarm -sbr <WANID> <VALUE> ds1alarm -sbi <WANID> <VALUE> Description: The command “ds1alarm”...
Page 141 Syntax: Description: The fr command provides status related to Frame Relay and its Control Protocols. This allows you to monitor DLCIs and aids troubleshooting. • • • • • • • Local Management User’s Guide MGR: This is the physical WPIM for the DLCI CKT: This is the virtual port number for the DLCI IF: This is the MIB II interface number for the DLCI DLCI: This is the circuit DLCI number...
Page 142 DLCI. Possible reasons for this are: The FR DTE bridge/router <-> FR DCE switch on the far side of the WAN cloud is not connected, or has polling error problems. Refer to the remote mibnav/LM screen for CSX...
Page 143 -ea Enables the Inverse Multiplexer Application. Options: -da Disables the Inverse Multiplexer Application. -eg <GROUPID> Enables the Inverse Multiplexer group designated by <GROUPID>. -dg <GROUPID> Disables the Inverse Multiplexer group designated by <GROUPID>. -ac <GROUPID> <INTERFACENUM> Adds the WAN channel designated by <INTERFACENUM>...
Page 144 MIB Navigator nat: Syntax: nat <options> Description: The nat command provides status relating to Network Address Translation. It allows you to assign a private network to an interface, to deﬁne an interface through which the internet can be accessed, and to create a public IP address to be used on the internet.
Page 145 netstat: Syntax: netstat <option> Description: The netstat command provides a display of general network statistics for the managed device. The netstat command must be used with one of the two display options. Options: -i Displays status and capability information for each interface. -r Displays routing information for each interface.
Page 146 MIB Navigator ppp: Syntax: Description: The ppp command provides additional status relating to PPP and its Network Control Protocols. Options: Not Applicable reset: reset Syntax: Description: The reset command allows you to perform a soft reset of the device. You are queried to conﬁrm the reset command to insure against unwanted resets.
Page 147 secondIP: Syntax: secondIP add <IPADDRESS> <INTERFACENUM> secondIP delete <IPADDRESS> <INTERFACENUM> Description: The secondIP command allows you to add or delete secondary IP addresses on the interface. Options: Not Applicable show: show <PROTOCOL> [TABLE] Syntax: Description: The show command displays information concerning various components of the device.
Page 148 MIB Navigator snmpbranch: Syntax: snmpbranch [IP address] [community name] [OID] Description: The snmpbranch command enables you to query another SNMP device. The command provides a display of objects that match the speciﬁed OID. If no match is made, no object is displayed. Options: Not Applicable Example:...
Page 149 snmpnext: Syntax: snmpnext [IPADDRESS] [COMMUNITY-STRING] [OBJECT-ID] Description: The snmpnext command allows you to query another device using SNMP. The next leaf of an object identiﬁer can be retrieved from that device by supplying an appropriate community string and the values of the object identiﬁer.
Page 150 MIB Navigator snmptree: Syntax: snmptree [IP address] [community name] Description: The snmptree command provides a display of all objects in the device and their corresponding values. Options: Not Applicable Example: traceroute: traceroute [IP address] Syntax: Description: The traceroute command generates a TRACEROUTE request to a speciﬁed IP address and provides a display of all next-hop routers in the path to the device.
Page 151: Special Commands
wanpq: Syntax: wanpq wanpq -ea wanpq -da wanpq -aip <IPADDRESS> wanpq -dip <IPADDRESS> Description: The wanpq command allows you to conﬁgure the WAN Priority Queue database. IPADDRESS is the Internet Protocol (IP) address being added to or removed from the Wide Area Network Priority Queue database. wanpq (with no options) Displays status information.
Page 152 MIB Navigator 3-36 Local Management User’s Guide...
Page 153: The Wan Physical Configuration Screen
WPIM-SY Conﬁguration This Appendix explains how to conﬁgure the WPIM-SY in a PPP or Frame Relay environment through Local Management. THE WAN PHYSICAL CONFIGURATION SCREEN To access the WAN Physical Conﬁguration screen from the Feature Selection screen, use the arrow keys to highlight the WAN Conﬁguration option, then press ENTER.
Page 154: Wpim-Sy Physical Configuration Fields
Appendix A: WPIM-SY Configuration WPIM-SY Physical Conﬁguration Fields The conﬁguration ﬁelds speciﬁc to the WPIM-SY shown in Figure A-1 are deﬁned as follows: Displays the Synchronous port electrical interface type. The selections toggle Sync Port Type — between V.35, X.21, None, RS232, and RS422. This ﬁeld always displays a Synchronous Port Type, even if the Synchronous Port is not the active WAN port.
Page 155: Wan Interface Configuration Screen Fields
WAN Interface Conﬁguration Screen Fields Figure A-2 shows the WAN Interface Conﬁguration screen ﬁelds speciﬁc to the WPIM-SY for PPP. Deﬁnitions of the ﬁelds are in <host name> Local Management WAN INTERFACE CONFIGURATION Interface Number: 002 Max Xmit Unit: 1526 ProtMgrIface: Active Protocol: PPP PPP MRU:...
Page 156: Ppp Configuration
Appendix A: WPIM-SY Configuration PPP CONFIGURATION This section provides step-by-step instructions for connecting the WPIM-SY to a DDS (Digital Data System) circuit in a PPP environment. This example assumes the setup shown in using two WPIM-SY modules installed in each host platform. HOST CSU/ PLATFORM...
Page 157: Wpim-Sy Interface Configuration
Use the arrow keys to highlight FORCE RTS True. Press the SPACE bar to set to ENABLE. Use the arrow keys to highlight FORCE DTR True. Press the SPACE bar to set to ENABLE. Set FORCE CTS and FORCE DSR to YES only if the CSU/DSU does not support NOTE these ﬂow control terms.
Page 158: Frame Relay Configuration
Appendix A: WPIM-SY Configuration FRAME RELAY CONFIGURATION This section provides instructions for connecting the WPIM-SY to a DDS (Digital Data System) circuit in a Frame Relay environment. Refer back to The line conﬁguration information shown in Table A-2 Telco Configuration Information Conﬁguration Information Required By User Clock Source Circuit Speed...
Page 159: Wpim-Sy Interface Configuration
Set FORCE CTS and FORCE DSR to YES only if the CSU/DSU does not support NOTE these ﬂow control terms. Use the arrow keys to highlight the SAVE command. Then press ENTER. The message “Save Done!” displays and Local Management saves the changes to memory and the device reboots. Local Management must be re-entered for any further configuration.
Page 160: Appendix Bwpim-E1 Configuration
Appendix A: WPIM-SY Configuration <host name> Local Management Interface Number: 000 Max Xmit Unit: ProtMgrIface: Active Protocol: FR FR LMI: [ANSI_94] DLCI Address: DLCI DCP En: DLCI DCP Stat: Comp Ratio: Circuit State: [Invalid] PORTS: SAVE [1-32] Figure A-4 WPIM-SY WAN Interface Conﬁguration Screen Make any other changes as desired.
Page 161: The Wan Physical Configuration Screen
WPIM-E1 Conﬁguration This Appendix explains how to conﬁgure the WPIM-E1 through Local Management. Sections of this chapter include: • Full T-1 Conﬁguration Using PPP • Fractional T-1 Conﬁguration Using PPP • Frame Relay Conﬁguration THE WAN PHYSICAL CONFIGURATION SCREEN To access the WAN Physical Conﬁguration screen from the Feature Selection screen, use the arrow keys to highlight the WAN Conﬁguration option, then press ENTER.
Page 162: Wpim-E1 Configuration Fields
Appendix B: WPIM-E1 Configuration WPIM-E1 Conﬁguration Fields The WPIM1 conﬁguration ﬁelds displayed on the Physical Conﬁguration screen in speciﬁc to the WPIM-E1. The service provider determines the settings for the following ﬁelds. Consult the NOTE service provider for the correct settings. Displays the status of the Timeslot Conﬁguration Table.
Page 163: The Wpim Timeslot Configuration Table
The WPIM Timeslot Conﬁguration Table The WPIM Timeslot Conﬁguration Table allows the user to conﬁgure the way in which the Cabletron WAN module uses the E1 line. The conﬁguration table consists of 32 timeslots. Only 31 of the timeslots are available for use, because the ﬁrst timeslot is used by the device to transmit framing data.
Page 164 Appendix B: WPIM-E1 Configuration 01-08 09-16 17-24 25-32 Site #1 is using the full E1, so all the timeslots must have an Interface assignment. Site #2 and Site #3 only use a fraction of the E1, but the total quantity of timeslots assigned must match those of Site #1.
Page 165: The Wan Interface Configuration Screen
THE WAN INTERFACE CONFIGURATION SCREEN Figure B-4 displays the WAN Interface Conﬁguration screen speciﬁc to the WPIM-E1 in PPP mode. <host name> Local Management Interface Number: Max Xmit Unit: ProtMgrIface: Active Protocol: PPP MRU: ECP Enable: ECP Status: CCP Enable: CCP Status: Comp Ratio: PORTS:...
Page 166: Wpim-E1 Physical Configuration
Appendix B: WPIM-E1 Configuration The line conﬁguration information shown in Table B-1 Telco Configuration Information Conﬁguration Information Required By User Line Coding Frame Type Clock Source WPIM-E1 Physical Conﬁguration Begin the WPIM-E1 conﬁguration by accessing the WAN Physical Conﬁguration screen through Local Management (Figure Use the arrow keys to highlight the [WPIM] field at the bottom of the screen.
Page 167: Wpim-E1 Interface Configuration
Use the arrow keys to highlight E1 Tx Clock Source. Press the SPACEBAR to select Local (no clock source provided by telephone company) or Loop (clock source provided by telephone company). If you are using a Local clock source, set only one end of the circuit for Local, the other end must be set for Loop.
Page 168: Fractional E1 Configuration Using Ppp
Appendix B: WPIM-E1 Configuration FRACTIONAL E1 CONFIGURATION USING PPP This section provides step-by-step instructions for conﬁguring the WPIM-E1 to use a fractional E1 circuit in a PPP environment. This example assumes the setup shown in platforms, each containing a WPIM-E1. In a fractional E1 setup, only a portion of the 32 timeslots or DS-0’s are used.
Page 169: Wpim-E1 Physical Configuration
WPIM-E1 Physical Conﬁguration Begin the WPIM-E1 conﬁguration by accessing the WAN Physical Conﬁguration screen through Local Management (Figure Use the arrow keys to highlight the [WPIM] field at the bottom of the screen. Press the SPACEBAR to toggle the field to the WPIM being configured, then press ENTER. Use the arrow keys to highlight the MgrType.
Page 170: Wpim-E1 Interface Configuration
Appendix B: WPIM-E1 Configuration WPIM-E1 Interface Conﬁguration This screen is accessed from the WAN Physical Conﬁguration screen. Proceed with the following steps to conﬁgure the WAN Interface through Local Management. Access the WAN Interface Configuration screen by using the arrow keys to highlight the WAN Int Config option and then press ENTER.
Page 171: Wpim-E1 Physical Configuration
The following information must be supplied to the service provider. • LMI type: Q.933-A The line conﬁguration information shown in Table B-3 Telco Configuration Information Conﬁguration Information Required By Customer Line Coding Frame Type Clock Source DSO’s (Timeslots) WPIM-E1 Physical Conﬁguration Begin the WPIM-E1 conﬁguration by accessing the WAN Physical Conﬁguration screen through Local Management (Figure...
Page 172: Wpim-E1 Interface Configuration
Appendix B: WPIM-E1 Configuration If you are using a Local clock source, set only one end of the circuit for Local, the other end must be set for Loop. CAUTION Use the arrow keys to highlight the SAVE command, then press ENTER. The message “Save Done!”...
Page 173: Wpim-Di Configuration
WPIM-DI Conﬁguration This chapter explains how to conﬁgure the WPIM-DI through Local Management. It provides instructions for setting up the WPIM-DI for full or fractional T-1 in a PPP environment, or for conﬁguring the WPIM-DI for Frame Relay. The WAN Physical Conﬁguration Screen To access the WAN Physical Conﬁguration screen from the Setup Menu screen, use the arrow keys to highlight the WAN Setup option, then press ENTER.
Page 174 Appendix C: WPIM-DI Configuration Displays the status of the Timeslot Conﬁguration table. This ﬁeld toggles NI/DI Timeslot View — between Active and New. The Active setting displays current Timeslot Conﬁguration table settings. The New setting allows you to change Timeslot Conﬁguration table settings. The default setting is Active (D/I).
Page 175 When the diDataEnable option is selected in the DI Enabled ﬁeld, data from the host NOTE device passes through the DI port and not the NI port on the host platform. WPIM-DI Timeslot Conﬁguration Table The WPIM Timeslot Conﬁguration table allows you to conﬁgure the way in which the WAN module uses the T-1 line.
Page 176 Appendix C: WPIM-DI Configuration 01-08 09-16 17-24 01-08 09-16 17-24 Figure C-3 Sample Timeslot Conﬁguration Site #1 is using the full T-1, so all the timeslots must have an Interface assignment. Site #2 and Site #3 only use a fraction of the T-1, but the total quantity of timeslots must match those of Site #1. Unused timeslots receive an Interface number of 000.
Page 177: The Wan Interface Configuration Screen
The WAN Interface Conﬁguration Screen This section describes the features of the WAN Interface Conﬁguration screen. Access the screen by using the arrow keys to highlight the WAN INT CONFIG option at the bottom of the Physical Conﬁguration screen, then press ENTER. The WAN Interface Conﬁguration screen shown in Figure C-4 displays.
Page 178: Wpim-Di Configuration
Appendix C: WPIM-DI Configuration WPIM-DI Conﬁguration This section provides step-by-step instructions for conﬁguring the WPIM-DI to use a full or fractional T-1 circuit in a PPP or Frame Relay environment. This simpliﬁed example assumes the setup shown in Figure C-5 using two host platforms containing a WPIM-DI at Site #1 and a WPIM-T1 at Site #2.
Page 179 Use the arrow keys to highlight NI/DI Timeslot View. Press the SPACE bar to select New, then press ENTER. The cursor moves to Timeslot #1 of the Timeslot Configuration table. Insert an interface number (refer to the NOTE on number, press ENTER, then use the arrow keys to highlight the next timeslot field. Exit this field by using the arrow keys.
Page 180: Wpim-Di Interface Configuration
Appendix C: WPIM-DI Configuration Use the arrow keys to highlight DI Enable. Press the SPACE bar to select On (Drop and Insert function enabled), or Off (Drop and Insert function disabled), or diDataEnable (Drop and Insert is enabled and the data that comes to the host goes to the DI port). Use the arrow keys to highlight the SAVE command, then press ENTER.
Page 181 Modem Settings for RS-232 Dial-up PPP Backup This appendix details the backup conﬁguration of a Frame Relay or PPP nailed-up connection using modems and the WPIM-SY. To avoid incurring a cost due to possible unintentional call(s) do not connect the modem line to the telephone wall jack until both the modem and the host platform have been conﬁgured.
Page 182: Appendix Dmodem Settings For Rs-232 Dial-Up Ppp Backup
Appendix D: Modem Settings for RS-232 Dial-up PPP Backup FastPro-II Modem Conﬁguration Origination Modem Conﬁguration The caller side must be conﬁgured for the following: • DTR off to on transition causes modem to automatically dial previously stored phone number. • Data mode of operation set to call is placed using the asynchronous call establishment command set.
Page 183: Answer Side Modem Configuration
Command &$ List the AT& command set settings to verify the conﬁguration. List the AT% command set settings to verify the conﬁguration. To verify that the settings have been saved, power down the modem, power it back up, enter the AT&$ command, and then the AT% command.
Page 184: Courier V.everything Modem Configuration
Appendix D: Modem Settings for RS-232 Dial-up PPP Backup Courier V.Everything Modem Conﬁguration Originate (Caller/backup) Side Modem Conﬁguration The caller side must be conﬁgured for the following: • DTR off to on transition causes modem to automatically dial previously stored phone number. •...
Page 185: Answer Side Modem Configuration
Answer Side Modem Conﬁguration The answer side must be conﬁgured for the following: • Normal DTR operations. • Normal CD operations. • Simultaneous DSR and CD. Use the Extended AT(tention) command set to conﬁgure the modem. Assume the default on all settings not speciﬁed, including DIP switch settings.
Page 186 Appendix D: Modem Settings for RS-232 Dial-up PPP Backup Local Management User’s Guide...
Page 187 AUI — Attachment Unit Interface. An IEEE 802.3 transceiver cable connecting the network device (such as a router) to the MAU (media access unit). Bandwidth on Demand — or closing multiple B channels) when the load in trafﬁc increases or decreases.
Page 188 Glossary Dynamic Host Conﬁguration Protocol is a protocol for automatic TCP/IP conﬁguration DHCP — that provides static and dynamic address allocation and management. Dial on Demand — Dial up WAN resources are accessed only when remote access is required and released as soon as the resource is no longer needed. Data Terminating Equipment.
Page 189 Glossary Internet address. A 32-bit address assigned to devices that participate in a network IP Address — using TCP/IP. An IP address consists of four octets separated with periods deﬁning network, optional subnet and host sections. IPX (Internet Packet Exchange) — A proprietary Network layer protocol developed by Novell and used in NetWare networks.
Page 190 Glossary Layer 3 of the OSI reference model that provides the protocol routing Network Layer — function. Node — Refers to a termination point for communication links; entity that can access a network. Open System Interconnection. An international standard developed by ITU (formally OSI —...
Page 191 Glossary Frames sent out by servers under IPX to check whether illegal copies of Serialization Frames — NetWare are in use on the network. Service Advertising Protocol — Protocol used in IPX for broadcasting information about services available on the network, such as ﬁle servers, CD-ROM drives and modem pools. Simple Network Management Protocol.
Page 192 Glossary Bridging technique used in Ethernet networks that allows transfer of Transparent Bridging — frames across intermediate nodes using tables associating end nodes with bridging addresses. Bridges are unknown to the end nodes. UDP — User Datagram Protocol. A connectionless protocol used to pass packets across an internet network, requiring no handshaking between source and destination.
Page 193 Backup Modem settings Bootstrap Protocol Client 1-38 Bootstrap Protocol Server 1-38 Bridge Setup bridge port pair administrative status port administrative status spanning tree protocol 1-29 Broadcast 1-40 Call Backup ISDN Call Backup Topology Conﬁguring the Network Broadcast Type on a port 1-40 Conﬁguring the UDP Broadcast Redirector...
Page 194 Index WAN Interface Configuration screen 2-10, A-3, WAN Physical Configuration screen 2-2, 2-3, 2-30, A-1, B-1, Local Management Screen Fields command fields display fields event message field input fields selection fields Management Agent description tree hierarchy MIB Navigator exiting 3-1, navigation commands other commands special commands...
