General Configuration Using Local Management

Setting the Host IP Address

To set the host IP address, perform the following steps:
1. Use the arrow keys to highlight the Host IP Address field.
2. Enter the IP address using Decimal Dotted Notation (DDN) format.
For example: 134.141.25.17
3. Press ENTER. If the IP address entered was a valid format, the cursor returns to the beginning
of the Host IP Address field. If the entry was not valid, the Event Message field displays
"INVALID IP ADDRESS OR FORMAT ENTERED". Local Management does not alter the
current value and refreshes the Host IP Address field with the previous value.
4. Use the arrow keys to highlight the SAVE command field.
5. Press ENTER. The Event Message field at the top of the screen displays "SAVED OK".

Setting the Default Gateway

To set the Default Gateway, perform the following steps:
1. Use the arrow keys to highlight the Default Gateway field.
2. Enter the IP address of the Default Gateway using DDN format.
For example: 134.141.79.121
3. Press ENTER. If the Default Gateway address entered was a valid format, the cursor returns to
the beginning of the Default Gateway field. If the entry was not valid, the Event Message field
displays "INVALID DEFAULT GATEWAY OR FORMAT ENTERED". Local Management
does not alter the current value and refreshes the Default Gateway field with the previous value.
4. Use the arrow keys to highlight the SAVE command field.
5. Press ENTER. The Event Message field at the top of the screen displays "SAVED OK".
104 CSX200 Family User's Guide
