Cabletron Systems CyberSWITCH CSX500 Setup Manual

PRE-CONFIGURATION INFORMATION

Only qualified personnel should install the CSX500. This Setup Guide is intended for the experienced
network equipment installer.
This Setup Guide describes the tools needed to configure the CyberSWITCH CSX500.
For further details concerning the operation of the CSX500, refer to the HSIM-W84 documentation on
NOTE
the QuickSet CD. The HSIM-W84 is similar to the CSX500. The difference is that the HSIM-W84 is a
module that is installed into a host device, while the CSX500 is a standalone unit. All other information
pertaining to the device is the same.
Figure 1 shows the CyberSWITCH CSX500.
WAN BRANCH OFFICE CONCENTRATOR

QuickSet CONFIGURATION SETUP

Tools needed

The following tools are required to configure the CSX500:
• Personal Computer (PC)
• Read Me First! instruction sheet (enclosed in the manual package)
• QuickSet CD (located in the shipping box with your device)
Cabletron Systems highly recommends using the QuickSet utility to configure the CSX500. Using the
NOTE
QuickSet CD will ensure a fast and correct installation. Using other methods may not produce correct or
as efficient results as the QuickSet CD.
PN 9032534-03
CSX500 SETUP GUIDE
ROUTER/SWITCH/INVERSE MUX
ENET
T1-1 T1-2
RX LNK LNK
TX STS STS
LAN
Figure 1 The CSX500
ASYNC
T1-3 T1-4
LNK
LNK LNK
STS STS STS
CONSOLE
TELCO
PWR
CPU
Page 1 of 2
