WPIM Cable Specifications

WPIM-DI

This section provides Cabletron Systems part number and connector specifications for the
WPIM-DI interface cables.
Table 46 shows the connector number, cable assembly description, cable and interface type,
connector type and part number information for the WPIM-DI interface.
Connector
Cable Assembly Description
Number
1 Network
2 Drop and Insert
Table 47 provides the WPIM-DI network interface cable pin assignments.
226 CSX200 Family User's Guide
Table 46 WPIM-DI Connector Information
Table 47 WPIM-DI Network
Pin Signal
1 Receive Ring
2 Receive Tip
3 AC Coupled Ground
4 Transmit Ring
5 Transmit Tip
6 AC Coupled Ground
7 AC Coupled Ground
8 AC Coupled Ground
Cable and Connector
Interface Type Type
DI RJ48
Part Number
9372094
