IPX Routing over Frame Relay

An additional step is required when routing IPX over Frame Relay. This step requires that entries
are created in the IPX Host Map. The IPX Host Map is a database of remote IPX hosts that are
defined generally by the WAN Network number and MAC Address, and more specifically by the
Interface Number and Data Link Connection Identifier (DLCI). The IPX Host Map helps a routing
decision by determining which circuit a packet should be forwarded to in a point to multi-point
Frame Relay connection.
Figure 61 shows how IPX Host Map entries are entered using the circuitmap command. The
circuitmap command is accessed from the
information on the circuitmap command.
The circuitmap command contains the following fields:
#Interface — An entry must be created for each remote Router connected via the Frame Relay
interface.
The Network is the IPX Network number associated with the Frame Relay network.
Network —
The Node is the MAC address of the remote router on the other end of the WAN link.
Node —
The Circuit ID is the DLCI identifying the virtual circuit connection to the Telco.
Circuit ID —

Enabling the IPX SAP Routing Protocol on a Port

IPX Source Advertisement Protocol (SAP) is used by IPX to exchange information about Novell
service providing nodes, such as file servers and print servers that are available. IPX SAP builds
and maintains a database, the Service Advertisement Table, containing the addresses and routes to
specific service providing nodes, and advertises this information over the network.
MIB Navigator
MIBNav-> circuitmap -s IPX 2 00000172 00:00:1d:02:d1:7a 102
# Interface
Network
00000172
# 2
Figure 61 Circuitmap Command
General Configuration Using Local Management
Screen. Refer to
Node Circuit ID
00:00:1d:23:a1:5b
102
CSX200 Family User's Guide 131
