WAN Configuration Using Local Management
T1 Interface Configuration
This section describes the features of the WAN Interface Configuration screen. Access the screen
by using the arrow keys to highlight the WAN Int Config option at the bottom of the WAN
Physical Configuration screen, pressing ENTER. The WAN Interface Configuration screen shown
in Figure 67 displays.
CSX200 Local Management
Interface Number:
Max Xmit Unit:
Line Coding:
Active Protocol:
SAVE
T1 WAN Interface Configuration Screen Fields
This section describes the WAN Interface Configuration screen fields.
Interface Number —
Interface Numbers you assigned to the Time Slots on the WAN Physical Configuration screen.
User-configured field that displays the maximum packet size that can be
Max Xmit Unit —
transmitted on the selected interface. The default settings for this field are 8191 for PPP and 4095
for Frame Relay.
Displays the Line Coding for Time Slots associated with this interface. This field
Line Coding —
displays JBZS, INV-HDLC, or None. The default setting for this field is None.
140 CSX200 Family User's Guide
WAN INTERFACE CONFIGURATION
[002]
[0]
[NONE]
[NONE]
RETURN
Figure 67 T1 WAN Interface Configuration Screen
Displays the active Interface Numbers. Use this field to configure the
Flash Image Version: xx.xx.xx
PT# IF# LID STATE PT# IF# LID STATE
001 001 Enet UP
002
