WAN Configuration Using Local Management
Displays the WPIM mode. The field toggles between PRIMARY and SECONDARY. In
Mode —
a device such as the BRIM-W6 where two WPIMs are utilized, but only one can be active at a
given time, the second WPIM installed or recognized defaults to Secondary.
Displays the status of the WPIM, Yes (active) or No.
Active —
Displays the interfaces available to each WPIM.
Ifaces —
WPIM-DDS Configuration Fields
The following configuration fields are displayed on the Physical Configuration screen shown in
Figure 75.
Displays the DDS Line Mode. The selections toggle between DDS-PRI
DDS Line Mode —
(primary) and DDS-CC (clear channel). This field should be set according to the instruction of
your service provider. The default setting for this field is DDS-PRI.
Displays the clock source as either Loop or Local. The Loop setting
DDS Tx Clock Source —
allows the WPIM-DDS to receive its timing information from the service provider and the Local
setting allows the WPIM-DDS to receive its timing information internally. If DDS-CC is chosen
for the DDS Line Mode then this field must be set to Loop. The default setting is Loop-Timing.
Displays the internal Loopback as either Line or None. Line loopback is
DDS Loopback —
reserved for network diagnostics only. The default is NONE.
DDS In-Speed — Informational purposes only. Displays 56000 (bps) for Primary DDS Line
Mode and 64000 (bps) for Clear Channel DDS Line Mode upon start-up.
DDS Out-Speed — Informational purposes only. Displays 56000 (bps) for Primary DDS Line
Mode and 64000 (bps) for Clear Channel DDS Line Mode upon start-up.
