T L
EST OCKING AND
C
ENTER
1. Place a block approxi-
mately 4 inches (10 cm)
high behind one of the front
tires.
2. Elevate the platform
to10-11 feet (3-3.4 m).
3. Slowly drive the tire onto
the block.
• The axle lock cylinders
should be locked (no move-
ment).
• The opposite tire should be
off the ground.
4. Lower the platform.
• The axle lock cylinders
should release.
• The suspended tire should
lower to the ground.
November 2009
Page 3-8
P
OSITION
"3084 Speed Level™ Sigma Lift" Service and Parts Manual
Pivot Pin
Bottom Left Side
ART_3166
M C
E C H A N I C A L
Figure 3-4: Floating Axle Lock Cylinder
Banjo Pin
Motor
Level Sensor
O M P O N E N T S
Axle Lock
Cylinder
