DRIVE FORWARD
111 - GRY/RED
LIFT
204 - RED/BLU
GAUGE PORT
STEER LEFT
108 - GRN/RED
LEFT REAR B
RIGHT REAR A
RIGHT FRONT B
LIFT PORT
LIFT RELIEF
RV1
STEER RELIEF
RV2
ORS
PRESSURE PORT
- TO PUMP -
ART_3146
October 2009
Page 1-12
HIGH TORQUE
313 - YEL/BLK
DRIVE REVERSE
110 - GRY/BLK
HAND PUMP
BRAKE RELEASE
STEER RIGHT
107 - ORG/WHT
FRONT
COUNTERBALANCE
PROPORTIONAL
333 - PPL/WHT
LEFT SIDE
"3084 Speed Level™ Sigma Lift" Service and Parts Manual
Figure 1-6: Main Hydraulic Manifold - 3084RT
Hydraulic Manifold
BACK
VALVES
PULL VALVE
BRAKE RELEASE
RIGHT SIDE
H M
Y D R A U L I C A N I F O L D
3084RT
HIGH SPEED
213 - YEL/WHT
TO TANK
ORLS
LINE SENSE
RIGHT FRONT A
LEFT FRONT B
RIGHT REAR B
LEFT REAR A
LEFT FRONT A
ORR
BRAKE PORT
GLS
STEER RIGHT
STEER LEFT
