GP400 C
ONTROL
L
O C A T I O N
• The GP400 Control Module processor is located in the lower control box.
• The GP400 Matrix Module is located in the upper control box.
Diagnostic information can be found in Section 4: Troubleshooting. Wiring information
can be found in Section 5: Schematics.
November 2009
Page 2-18
M S
ODULE ETUP
"3084 Speed Level™ Sigma Lift" Service and Parts Manual
G P4 0 0 C
Figure 2-21: GP400 Module Locations
Upper Controls
GP400
Matrix Module
ART_3156
M S
O N T R O L O D U L E E T U P
Lower Controls
GP400
Control Module
Terminal
Block
Module
Diagnostic LED
