DRIVE FORWARD
111 - GRY/RED
LIFT
204 - RED/BLU
GAUGE PORT
STEER LEFT
108 - GRN/RED
LEFT REAR B
RIGHT REAR A
RIGHT REAR B
LIFT PORT
LIFT RELIEF
RV1
STEER RELIEF
RV2
ORS
PRESSURE PORT
- TO PUMP -
ART_3147
"3084 Speed Level™ Sigma Lift" Service and Parts Manual
T
R O U B L E S H O O T I N G
HIGH TORQUE
313 - YEL/BLK
DRIVE REVERSE
110 - GRY/BLK
HAND PUMP
BRAKE RELEASE
STEER RIGHT
107 - ORG/WHT
FRONT
COUNTERBALANCE
LEFT SIDE
- 3 0 8 4 E S - - C
M O D E L
Figure 4b-15: Hydraulic Manifold, ES
Hydraulic Manifold
BACK
VALVES
PULL VALVE
BRAKE RELEASE
RIGHT SIDE
I
O M P O N E N T L L U S T R A T I O N S
3084ES
HIGH SPEED
213 - YEL/WHT
TO TANK
ORLS
MAIN
RELIEF
VALVE
RIGHT FRONT A
LEFT FRONT B
RIGHT REAR B
LEFT REAR A
LEFT FRONT A
ORR
BRAKE PORT
STEER RIGHT
STEER LEFT
November 2009
Page 4b-41
