H
Y D R A U L I C
D S
RIVE HAFT
Caution: Be careful not to damage the drive shaft when removing the old seal.
1. Remove the shaft key.
2. Remove the snap ring.
3. Remove the shaft seal.
• Check the surface of the shaft and the housing for imperfections.
4. Install new shaft seal.
• Cover the keyway portion of the drive shaft with tape to prevent damage to the seal during
installation.
• Coat the shaft seal with grease.
• Seat the shaft seal with a seal setting tool.
5. Install the snap ring.
6. Install the shaft key.
H
YDRAULIC
Pump rebuild should be performed only by a qualified mechanic. Contact MEC
Technical Support before attempting to rebuild the pump.
October 2009
Page 1-8
P S
U M P E A L S
S R
EAL EPLACEMENT
P R
UMP EBUILD
"3084 Speed Level™ Sigma Lift" Service and Parts Manual
- 3084RT
H P - 3 0 8 4 R T
Y D R A U L I C U M P
