C
ONTROLS
L C
O W E R
Raise
2
(Green)
Lower
3
(Green)
Battery
11
Disconnect
Keyswitch
1
ART_3091
CONTROL DESCRIPTION
Selector Switch PLATFORM
(key can be
1 BASE
removed in any
position) OFF
2 RAISE Button Press and hold to elevate the platform. Release to stop elevation. Throttle activation is automatic.
3 LOWER Button Press and hold to lower the platform. Release to stop lowering.
EMERGENCY Press to stop all machine functions.
4
STOP Switch Turn clockwise to reset.
5 Hour Meter Indicates total elapsed time of machine operation.
6 Start Button Press to start engine. Release when engine starts.
7 Choke/Glow Operate when starting in cold start conditions.
Start Delay Light Prevents over-cranking of engine. When lit, starter is disabled. After approximately 35 seconds the light
8
will go out and starter will operate.
9 Circuit Breaker Trips when there is excessive electrical load. Push to reset.
EMERGENCY Push and hold the toggle switch Down to fully lower the platform.
10
LOWERING Switch
11 Battery Disconnect Battery power supply. Turn OFF and padlock to secure machine from unauthorized use.
Fuel Selector Turn switch to select Gasoline or Propane.
12
(Dual Fuel Only)
November 2009
Page 2-8
- 3084RT D
O N T R O L S
Emergency Stop
4
Fuel Select Switch
12
(Dual Fuel Only)
Select to operate from the platform control panel.
Select to operate from the base control panel.
Select to stop operation from either control panel.
"3084 Speed Level™ Sigma Lift" Service and Parts Manual
F
U A L U E L
Figure 2-4: Lower Controls--Dual Fuel
Hour Meter
5
10
Emergency
Lowering
C
O N T R O L S
/ D
I E S E L
Start Delay
8
7
Choke (Dual Fuel)
Glow (Diesel)
6 Start
9 Circuit Breaker
