Mec Speed Level 2684 RT Service And Parts Manual page 36

D B
RIVE AND
W D
H E E L
NOTE: Refer to Section 3 for Remove and Install instructions.
Refer to Parts Section D.
There are four (4) hydraulic fixed-displacement gear wheel motors to provide power to
all four wheels.
D
YNAMIC
The two (2) rear wheel motors have integral spring-held brakes. Hydraulic pressure
developed in the drive circuit during drive mode releases the brakes. A fixed orifice in
the brake circuit controls the brake application to provide a smooth stop.
October 2009
Page 1-16
S
RAKE YSTEM
R I V E
B C
RAKING IRCUIT
"3084 Speed Level™ Sigma Lift" Service and Parts Manual
D B S
R I V E A N D R A K E Y S T E M
