L C
O W E R
Raise
2
(Green)
Lower
3
(Green)
Battery
8
Disconnect
Keyswitch 1
ART_3245
CONTROL DESCRIPTION
Selector Switch PLATFORM
(key can be
1 BASE
removed in any
position) OFF
2 RAISE Button Press and hold to elevate the platform. Release to stop elevation. Throttle activation is automatic.
3 LOWER Button Press and hold to lower the platform. Release to stop lowering.
EMERGENCY Press to stop all machine functions.
4
STOP Switch Turn clockwise to reset.
5 Hour Meter Indicates total elapsed time of machine operation.
6 Charge Indicator Indicates state of battery charge.
7 Circuit Breaker Trips when there is excessive electrical load. Push to reset.
8 Battery Disconnect Battery power supply. Turn OFF and padlock to secure machine from unauthorized use.
EMERGENCY Push and hold the toggle switch Down to fully lower the platform.
9
LOWERING Switch
"3084 Speed Level™ Sigma Lift" Service and Parts Manual
- 3084ES E
O N T R O L S
Emergency Stop
4
Select to operate from the platform control panel.
Select to operate from the base control panel.
Select to stop operation from either control panel.
L E C T R I C
Figure 2-5: Lower Controls--Electric
Hour Meter
5
C
O N T R O L S
Charge Indicator
6
Emergency
9
Lowering
Circuit
7
Breaker
November 2009
Page 2-9
