The following table applies to Figure 5-11, Figure 5-12 and Figure 5-13.
Callout
Description
MA-1
MAIN MANIFOLD
CBV1
Counter Balance Valve, Drive
CBV2
Counter Balance Valve, Drive
CL1
Coil - Speed/Torque/Steer #8
CL2
Coil - Lift Valve #10
CL3
Coil - Proportional
CP1
Cavity Plug, Stopped
CV1
Check Valve, Load Sense Steer
EC1
Priority Flow Control
EP1
Piloted Poppet Valve - Torque/Speed
EP2
Piloted Poppet Valve - Torque/Speed
FD1
Flow Divider/Combiner
FD2
Flow Divider/Combiner
HP1
Hand Pump, Brake Release
LS1
Load Sense Shuttle
MP1
Manual Push Brake Release Valve
OD1
Orifice Disc, Brakes, 0.035
OPL1
Orifice Plug, Steering, 0.087
OPL2
Orifice Plug, Flow Divider Bleed, 0.025
OPL3
Orifice Plug, Flow Divider Bleed, 0.025
OPL4
Orifice Plug, Stopped
OPL5
Orifice Plug, Stopped
PD1
Pilot Valve, Series Parallel, 4-Way / 3-Position
PD2
Pilot Valve, Series Parallel, 4-Way / 3-Position
PD3
Pilot Valve, Series Parallel, 4-Way / 3-Position
PLG4
Port Plug
PLG6
Port Plug
RV1
Relief Valve, Lift, 2500 PSI
RV2
Relief Valve, Steering, 2000 PSI
RV7
Relief Valve, 3000 PSI Main
SV1
Spool Valve, Lift, 3-Way
SV2
Spool Valve, Steer, 4-Way / 3-Position
SV3
Spool Valve, Series Parallel, 4-Way / 3-Position
SV4
Spool Valve, Series Parallel, 4-Way / 3-Position
SVD1
Spool Valve, Drive, 4-Way / 3-Position
May 2010
Page 5-14
3 0 8 4 E S E
M
ODEL
Callout
CYL1
CYL2
MA-2
CV3
CV4
CV5
CV6
CV7
CV8
CV9
CYL4
CYL5
CYL6
CYL7
ORF4
ORF5
RV3
RV4
RV5
RV6
SV8
SV9
MA-3
CYL3
ORF3
SV5
RR
SV6
SV7
FL1
"Speed Level™ Sigma Lifts" Service and Parts Manual
M
- H
L E C T R I C
O D E L
Description
STEERING COMPONENTS
Steer Cylinder, Right
Steer Cylinder, Left
TILT COMPONENTS
Combination Valve Manifold - Tilt
Check Valve, Tilt, Side/Side Load Sense
Check Valve, Tilt, Front/Rear Load Sense
Check Valve, 10PSI Oscillating Axle
Check Valve, Tilt Cyl, Front/Rear
Check Valve, Tilt Cyl, Front/Rear
Check Valve, Tilt Cyl, Side/Side
Check Valve, Tilt Cyl, Side/Side
Tilt Cylinder, Front/Rear
Tilt Cylinder, Side/Side
Axle Lock Cylinder
Axle Lock Cylinder
Orifice, 0.040, Tilt, Side/Side
Orifice, 0.040, Tilt, Front/Rear
Relief Valve, Tilt Cyl Front/Rear, 2500 PSI
Relief Valve, Tilt Cyl Front/Rear, 2500 PSI
Relief Valve, Tilt Cyl Side/Side, 2500 PSI
Relief Valve, Tilt Cyl Side/Side, 2500 PSI
Spool Valve, Tilt Front/Rear
Spool Valve, Tilt Side/Side
LIFT COMPONENTS
Lift Cylinder Manifold
Lift Cylinder
Orifice, 0.067 Descend
Solenoid Valve, 12V, Dual Coil
Wheel Motors
LF
Wheel Motor - Left Front
LR
Wheel Motor w/ Brake - Left Rear
RF
Wheel Motor - Right Front
Wheel Motor w/ Brake - Right Rear
Spool Valve - Right Wheel Motor Bypass
Spool Valve - Left Wheel Motor Bypass
RESERVOIR
Filter, 10 Micron, Fluid Return
P1
Pump, Hydraulic Fluid
- 3 0 8 4 E S
Y D R A U L I C
