P L
LATFORM
There are two (2) hydraulic cylinders in the platform leveling system. These cylinders
work in conjunction with a pivot mount to allow the platform and boom to tilt front-to-rear
and side-to-side in order to provide a level work platform.
Automatic leveling is controlled by the GP400 processor.
Platform Leveling
Manifold
SV3 SV1
Front to Rear
Leveling
Cylinder
Side to Side
"3084 Speed Level™ Sigma Lift" Service and Parts Manual
S
EVELING YSTEM
Leveling
Cylinder
P
L A T F O R M
Figure 1-14: Platform Leveling Manifold and Cylinders
INSIDE CONTROL MODULE
Platform Leveling
Manifold
Main Manifold
L S
E V E L I N G Y S T E M
ART_3135
October 2009
Page 1-25
