P
A R K I N G
The machine can be winched or moved short distances in case of power failure at
speeds not to exceed 5 MPH (8.05 km/h). Before towing or winching the machine, it is
necessary to release the brake. Reset the brakes after winching or towing.
AFTER DISENGAGING BRAKES THERE IS NOTHING TO STOP THE MACHINE'S
TRAVEL. MACHINE WILL ROLL FREELY ON SLOPES. BE ON GUARD AGAINST
RUNAWAY.
Prior to manually releasing brakes, insure wheels are chocked to prevent
unintentional movement.
D
ISENGAGE
• Chock the wheels.
• Push and hold release valve.
• Using the hand pump on the manifold, pump valve until pressure is built and valve cannot be
pumped.
• Machine is now ready for towing.
E
NGAGE
D :
RIVING
• Pull out the manual brake release
valve to reset brakes.
NOTE: Brakes will reset automatically when drive
function is activated.
May 2010
Page XII
B T
R A K E A N D
B B
RAKES EFORE
B B
RAKES EFORE
"Speed Level™ Sigma Lifts" Service and Parts Manual
C
O W I N G I R C U I T
T :
OWING
Hand Pump
Figure 1-5: Disengage Brakes
Release Valve
ART_2423
