Typical Cylinders, Exploded View - Mec Speed Level 2684 RT Service And Parts Manual

G C
ENERAL YLINDER
CYLINDERS ARE HEAVY. SUPPORT CYLINDERS BEFORE REMOVING
HARDWARE THAT SECURES THE CYLINDER TO THE MACHINE.
Rod
ART_2040
R
E M O V A L
NOTE: Refer to Section 3 for Remove and Replace instructions, and the Parts Manual for a list of hardware specific to
the cylinder being repaired.
1. Tag hoses for proper reassembly.
2. Disconnect hoses and IMMEDIATELY cap the openings to prevent contamination.
3. Remove cylinder from the machine as described in Section 3.
October 2009
Page 1-28
R
EPAIR
Seals
Head
Typical Single Acting Cylinder
Seals
Rod
Head
Typical Dual Acting Cylinder
"3084 Speed Level™ Sigma Lift" Service and Parts Manual
Figure 1-17: Typical Cylinders, Exploded View
Piston
Seals
Piston Securing Nut
Piston Securing Nut
Seals
Piston
Seals
G C R
E N E R A L Y L I N D E R
Return to Tank
Vent to Tank
Barrel
Pressure
Pressure
and
Return
Barrel
E P A I R
