Mec Speed Level 2684 RT Service And Parts Manual page 39

1
4 6
TORQUE
SEQUENCE
5
2
7
PRE-TORQUE = 10 FT LBS
FINAL TORQUE = 50 FT LBS
6
19
31
DT701 Series Motor Components
1. * Dust Seal
2. * High Pressure Seal
3. * Metal Backup Shim
4. * Backup Seal
5. * Shaft Seal
6. * Housing Seal
7. * Body Seals (3)
8. * Manifold Seal
9. * Commutator Seal
10. * O-Ring Seal
11. * Backup Seal
12. Retaining Snap Ring
13. Bearing Spacer
14. 1.5" Bearing
15. Thrust Washers (2)
16. Thrust Bearing
*Seal kit components
"3084 Speed Level™ Sigma Lift" Service and Parts Manual
3
23
22
7
21
20
15
4
2
13
3
12
1
17. Housing
18. Rear Housing Bearing
19. Drive Link
20. Divider Plate
21. Rotor Assembly
22. Manifold
23. Commutator Assembly
24. Endcover Piston
25. Piston Spring
26. Endcover
27. I.D. Tag Assembly
28. Assembly Bolts (7)
29. Shaft
30. Shaft Key
31. Shaft Nut
Figure 1-10: Front Wheel Motor (DT701) Exploded View
"V" Marks for Reassembly
7
11
24
26
25
10
9
8
30
17
16
5
14
1.5" BEARING
DUST SEAL
D B
R I V E A N D R A K E
28
27
18
29
3 4
5
SHAFT SEAL
BACKUP SEAL
METAL BACKUP RING
ART_2548
October 2009
Page 1-19
S
Y S T E M
