Table 4a-2: EZ-Cal Setup Table
OPERATION ID
6A 6A-1
CHANGE
6A-2
DEFAULTS
6D
6B-1
TILT SETUPS
6B-2
6B-3
6B-4
6C
6C-1
HEIGHT SETUP
6C-2
6C-3
(CE OPTION ONLY)
6C-4
6C-5
6C-6
6D
6D-1
LOAD SETUPS
(CE OPTION ONLY)
6D-2
6D-3
6D-4
6D-5
6E
6E-1
INTERLOCKS
6E-2
6E-3
Delays
6E-4
Sub Menu
6E-4a
6E-4b
"3084 Speed Level™ Sigma Lift" Service and Parts Manual
T
R O U B L E S H O O T I N G
S
E T U P
PERSONALITY FACTORY SETTING
Customer
Model
Calibrate Level? Y = ENTER N = ESC
WARNING! Refer to Tilt Sensor Calibration instructions before attempting calibration
Tilt Shutdown
Elevated Shutdown
Axle Tilt
Elevation @
Calibrate Height Start Calibration
Minimum Lift
Samples
Tilt Correction
Slow Down
Calibrate Load Start Calibration
Faulty Load
Dynamic Scale
Delay Up
Delay Down
Trigger Only
Trigger Wait
Function hold
Delays
Throttle Delay
Start Delay
- 3 0 8 4 R T
EXPLAINATION
Identifies Base Model
5: XX84RT
Must be set when GP400 is Replaced
5 = ANSI Select from these choices only
6 = CE
Follow instructions in
Section 2 - Level Sensor Calibration
0 = Never Function shutdown tilted when platform stowed
1 = Lift & Drive Function shutdown tilted when platform elevated
Maximum deflection of axle before elevated drive
3.0 deg
interlock
13%
See Section 2 for calibration of Height Sensor
1.0 sec Calibration setting - do not change
0.10 sec Calibration setting - do not change
Disabled Calibration setting - do not change
10% Calibration setting - do not change
See Section 2 for calibration of
CE Overload System
100% Calibration setting - do not change
95% Calibration setting - do not change
0.0 sec Not Used
0.0 sec Not Used
10.0 sec Enable bar held without operation before interlock
Delay after enable bar pulled before function
0.0 sec
enabled
0.2 sec Function enabled after operator release
— Sub category, press ENTER to access
0.0 sec Delay before throttle enabled
Interlocks start to protect start system from
10.0 sec
overheat
