The electronic control system used on the 3084ES is designed for very low
maintenance and long trouble free operation. The system consists of three electronic
microprocessor controlled modules; the Matrix Module, P600 Motor Control Module
and the GP400 Processor. They communicate through low voltage digital signal
technology called CANBUS communication.
The modules are protected against short circuit and reverse polarity to protect against
part failure or incorrect plug connections.
NEVER ATTEMPT TO SUPPLY BATTERY POWER, OR VOLTAGE HIGHER
THAN 12 VOLTS TO ANY PART OR MODULE IN THIS SYSTEM, AS
CATASTROPHIC FAILURE OF THE MODULES MAY RESULT.
USE OF HIGH PRESSURE WASHING EQUIPMENT DIRECTLY ON THE
MODULES CAN FORCE WATER INTO SEALED CONNECTION AND CAN
CAUSE A TEMPORARY SYSTEM SHUT-DOWN. HIGH PRESSURE
WASHING WITHIN THE VICINITY OF THE MODULES IS HIGHLY
DISCOURAGED.
