Cabletron Systems SmartSwitch 6500 User Manual page 87

Virtual Ports and Static Connections
Use the
1.
set portconfig
Smart6500 # set portconfig
PortNumber()
PortAdminStatus(up)
IlmiAdminStatus(up)
SigType(autoConfig)
SigRole(network)
InterfaceType(private)
MaxVpiBits(0)
MaxVciBits(13)
MaxSvcVpci(0)
MinSvcVci(32)
MaxVccs(8192)
MaxSvpVpci(0)
MaxVpcs(0)
Smart6500 #
Use the
2.
set portconfig
Smart6500 # set portconfig
PortNumber()
PortAdminStatus(up)
IlmiAdminStatus(up)
SigType(nniPvc)
SigRole(network)
InterfaceType(private)
MaxVpiBits(0)
MaxVciBits(12)
MaxSvcVpci(7)
MinSvcVci(32)
MaxVccs(8192)
MaxSvpVpci(7)
MaxVpcs(7)
Smart6500 #
Note The command
Normally, you would turn off signaling and set the
instance of
command to turn signaling off on physical port
: 7a1
:
:
: nnipvc < Turn off signaling by setting SigType to nnipvc
:
:
:
:
:
:
:
:
:
command to assign two bits to
: 7a1
:
:
:
:
:
: 1
:
:
:
:
:
:
is used here twice for the purposes of clarity only.
set portconfig
.
set portconfig
:
7a1
< Default MaxVpiBits = 0
< Default MaxVciBits = 13
.:
MaxVpiBits
< Set to 1 — this translates to VPIs = 2
< Notice that MaxVciBits has reduced itself by 1 bit
MaxVpiBits
Virtual Ports
1
-1 = 1
within the same
SmartSwitch 6500 User Guide 6-9
