Table A-2
Specification
Operating temperature
Operating humidity
Table A-3
Media Port Speed Framing
SMF-IR 155 Mbps STS-3c or STM-1
SMF-IR 622 Mbps STS-12c or STM-4 SC
SMF-LR 155 Mbps STS-3c or STM-1
SMF-LR 622 Mbps STS-12c or STM-4 SC
MMF 155 Mbps STS-3 or STM-1
MMF 622 Mbps STS-12c or STM-4 SC
Cat. 5 155 Mbps STS-3c or STM-1
UTP
75 ohm 44.7 Mbps DS-3
coax nonchannelized
75 ohm 34.3 Mbps E-3 nonchannelized BNC,
coax
Table A-4
Protocol
Signaling
A-2 SmartSwitch 6500 User Guide
Physical Specifications (Continued)
Value
5 to +40 C (41 to 104 F)
5% to 90% RH, non-condensing
ATM Port Specifications
Connector
SC
SC
SC
RJ-45
BNC,
female
female
Protocols Standards and Specifications
Standard
ATM Forum UNI 3.0
ATM Forum UNI 3.1
ATM Forum UNI 4.0
ATM Forum ILMI 4.0
Max. Rx
Max. Tx Min. Tx
power
Power power
-8 dBm -15 dBm -8 dBm
-8 dBm -15 dBm -7 dBm
0 dBm -5 dBm -8 dBm
+2 dBm -3 dBm -7 dBm
-14 dBm -19 dBm -14 dBm
-14 dBm -20 dBm -14 dBm
-- -- --
n/a n/a n/a
n/a n/a n/a
Specifications
Min. Rx Range
power
-31 dBm 15 Km
-28 dBm 15 Km
-34 dBm 50 Km
-28 dBm 45 Km
-31 dBm 2 Km
-26 dBm 500 m
-- 100 m
n/a 150 m to
DSX
n/a 150 m to
DSX
