UNI Routes

5.3 UNI ROUTES
Use the command to create UNI routes. For example, connect an end station adapter (with MAC address
add atmroute
00:11:22:33:44:55) to port 7A2 of the SmartSwitch 6500. If the adapter does not support ILMI or its ILMI is
incompatible with the SmartSwitch 6500, you must create a static UNI route between the adapter and port 7A2 of the
SmartSwitch 6500. The following is an example:
1. Enter the
show netprefix
Smart6500 # show netprefix
PortNumber(ALL)
Port# NetPrefix
============================================================================
7A2 39:00:00:00:00:00:00:00:00:00:14:59:00
Smart6500 #
Reconfigure the adapter with an ATM address made from the netprefix of port 7A2 and the adapter's
2.
MAC address: 39:00:00:00:00:00:00:00:00:00:14:59:00:00:11:22:33:44:55:00.
Use the
3.
add atmroute
new ATM address.
Smart6500 # add atmroute
PortNumber()
AtmAddress()
PrefixLength(152)
Index(0)
Type(Internal)
Scope(0)
MetricsTag(0)
Smart6500 #
Enter the
4.
show atmroute
Smart6500 # show atmroute
AddressNumber(ALL)
No. Port Route Address
================================================================================
1 7B4 39:00:00:00:00:00:00:00:00:00:14:41:80:00:20:d4:14:41:80
2 7B4 39:00:00:00:00:00:00:00:00:00:14:41:80:00:20:d4:14:41:81
3 -- 39:00:00:00:00:00:00:00:00:00:14:59:00
4 7A2 39:00:00:00:00:00:00:00:00:00:14:59:00:00:11:22:33:44:55
5 -- 39:00:00:00:00:00:00:00:00:00:28:e9:80
6 -- 39:00:00:00:00:00:00:00:00:00:28:f5:00
7 7B4 47:00:79:00:00:00:00:00:00:00:00:00:00:00:a0:3e:00:00:01
8 5B2 52:00:00:00:00:00:00:00:00:00:14:51:80
Smart6500 #
The UNI route appears in the table as
For UNI routes to work with certain devices, ILMI may also need to be disabled
Note
on the SmartSwitch 6500. Use the
the SmartSwitch 6500 on a per-port basis.
5-4 SmartSwitch 6500 User Guide
command to obtain the netprefix of port 7A2:
: 7a2
command to create a static UNI route that specifies port 7A2 and the adapter's
: 7a2
: 39:00:00:00:00:00:00:00:00:00:14:59:00:00:11:22:33:44:55:00
:
:
:
:
:
command to check that the UNI route was added.
:
, with Protocol Type of
Route 4
Type Protocol
I
I
I
I
I
I
I
I
(management).
MGMT
command to disable ILMI on
set portconfig
Routing
MGMT
MGMT
PNNI
< Our added UNI route
MGMT
PNNI
PNNI
MGMT
MGMT
