Multi-level PNNI Topology
The first byte of the peer group ID indicates the peer group's level. It also indicates
Note
the number of significant bits used in the peer group ID. For example, if the level
indicator is 50 (80 decimal), then 80 bits / 8 = 10 bytes; and only 10 of the 13 bytes
are significant (39:00:00:00:00:00:00:00:00:00). If you create a new peer group
ID, make sure that the bytes you change are within the range of significant bytes
for the peer group's level.
Use the
3.
show pnnilink
example, switch SWA3 sees links to the other two members of its peer group:
A3 # show pnnilink
Num(ALL)
Num Port Node Remote Node
Number Index IP Addr
===========================================================================
1 7A2 1 206.61.237.20
2 7A3 1 206.61.237.19
A3 #
4. Select switch SWA3 to be the PGL of group A and switch SWB3 to be the PGL of group B.
Use the
5.
add pnninode
A3 # add pnninode
NodeIndex(2)
NodeLevel(72)
ComplexRepresentation(N)
A3 #
Do the same for switch SWB3:
B3 # add pnninode
NodeIndex(2)
NodeLevel(72)
ComplexRepresentation(N)
B3 #
Use the
6.
set pnnipglelection
are elected as PGLs within their respective peer groups:
A3 # set pnnipglelection
NodeIndex(1)
LeadershipPriority(0)
ParentNodeIndex(0)
InitTime(15)
OverrideDelay(30)
ReElectTime(15)
A3 #
4-4 SmartSwitch 6500 User Guide
command to check the PNNI connectivity within each peer group. For
:
Hello State
2WayInside
2WayInside
command to add a second, higher-level, node to switch SWA3:
:
:
:
:
:
:
command to set SWA3 and SWB3's leadership priority so that they
:
: 205
: 2
:
:
:
Link Type
Lowest Level Horizontal Link
Lowest Level Horizontal Link
< Specifies node number 2
< 72 is above the group A's level of 80
< Specifies node number 2
< 72 is above the group B's level of 80
< Highest priority in election process
< Node 2 will represent the peer group A in the parent group
