APPENDIX A SPECIFICATIONS

This appendix lists the technical specifications for the SmartSwitch 6500 switch.
Table A-1
Specification
Processor
Switching engine
Max I/O ports*
Port-to-port latency
CPU DRAM memory
Buffer memory (cells)
Flash memory
Serial port
Ethernet port
*On TSM/CPU modules, ports 7b4
and 8b4 are reserved for the CPU, and
can not support connections
Table A-2
Specification
Dimensions chassis
Dimension (CSM, TSM)
Weight (empty chassis)
Weight (CSM, TSM)
Approx. power requirements (5V)
Hardware Specifications
Value
i960HD, 66 MHz
10 Gbps, non-blocking
Up to 63 OC-3, DS-3, or E3 — Up to 15 OC-12
11 microseconds
128 MB
512 K
16 MB
RS-232c compliant; RJ-45 connector
IEEE 802.3 compliant; RJ-45 connector
Physical Specifications
Value
62.2 cm H x 43.3 cm W x 35.6 cm D
24.5" H x 17.3" W x 14" D
41.9 cm H x 3.1 cm W x 28.6 cm D
16.5" H x 1.2" W x 11.25" D
13.6 kg (30 lbs)
2.3 kg (5 lbs)
TSM + two OC3 I/O modules = 12 Amps
CPU module = 2 Amps
CSM = 8 Amps
SmartSwitch 6500 User Guide A-1
