6 VIRTUAL PORTS AND STATIC
CONNECTIONS
6.1

PVC CONNECTIONS

The SmartSwitch 6500 supports Permanent Virtual Circuits (PVCs), both point-to-point and point-to-multipoint. Use
PVCs to connect devices (that do not support SVCs) to a switch's local client. Also, use PVCs to make connections
through the SmartSwitch 6500 between devices that support only PVCs.
Use point-to-point PVCs to connect one end node to another for two-way communication. Use point-to-multipoint
PVCs to connect a broadcast end node to a group of receiving end nodes; traffic is one way.
Note PVCs use traffic descriptors to define their traffic characteristics. See Chapter 7,
"Traffic Management," Section 7.1.1 for further information on traffic
descriptors.
6.1.1

Point-to-Point PVCs

The procedure for setting up a PVC connection between two end nodes through the SmartSwitch 6500 consists of
specifying the ports and the Virtual Path Connection Identifier and Virtual Channel Identifiers (VPCI and VCI).
Use
1.
add trafficdescriptor
Smart6500 # add trafficdescriptor
Executing this command : add TrafficDescriptor
TrafficType(UBR)
TrafficDescriptorType(2)
PCRCLP01(100)
QOSCLASS(1)
AalType(5)
Smart6500 #
to define a traffic descriptor to use with the PVC:
: cbr
:
:
:
:
SmartSwitch 6500 User Guide 6-1
