SmartCell 6A000 User
Guide
35 Industrial Way
Rochester, NH 03866
USA
(603) 332-9400
Part Number 04-0045-02 Rev-A
Order Number 9032539

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SmartCell 6A000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Cabletron Systems SmartCell 6A000

Summary of Contents for Cabletron Systems SmartCell 6A000

  • Page 1 SmartCell 6A000 User Guide 35 Industrial Way Rochester, NH 03866 (603) 332-9400 Part Number 04-0045-02 Rev-A Order Number 9032539...
  • Page 2 Cabletron Systems reserves the right to make changes in specifications and other information contained in this document without prior notice. The reader should in all cases consult Cabletron Systems to determine whether any such changes have been made. The hardware, firmware, and software described in this manual are subject to change without notice.

  • Page 3: Fcc Class A Notice

    This equipment uses, generates, and can radiate radio frequency energy and, if not installed in accordance with the SmartCell 6A000 User Guide, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause interference, in which case the user will be required to correct the interference at his own expense.

  • Page 4: Declaration Of Conformity Addendum

    Equipment Type/Environment: We the undersigned, hereby declare, under our sole responsibility, that the equipment packaged with this notice conforms to the above directives. Manufacturer: Legal Representative in Europe: SmartCell 6A000 User Guide 89/336/EEC 73/23/EEC Cabletron Systems, Inc. 35 Industrial Way P.
  • Page 5 Do not use optical instruments to view the laser output. The use of optical instruments to view laser output increases eye hazard. When viewing the output optical port, you must remove power from the network adapter. watts. or 8 x 10 SmartCell 6A000 User Guide v sr-1.
  • Page 6 Reconnect cable and check for proper mating. If problems remain, gently wipe out optical port with a DRY fiber port cleaning swab and repeat step 1. To avoid contamination, replace port caps on all fiber optic devices when not in Caution use. SmartCell 6A000 User Guide...
  • Page 7 REGULATORY COMPLIANCE SUMMARY SAFETY The SmartCell 6A000 meets the safety requirements of UL 1950, CSA C22.2 No. 950, EN 60950, IEC 950, and 73/23/EEC. The SmartCell 6A000 meets the EMC requirements of FCC Part 15, EN 55022, CSA C108.8, VCCI V-3/93.01, EN 50082-1, and 89/336/EEC.

  • Page 8: Revision History

    REVISION HISTORY Document Name: SmartCell 6A000 User Guide Document Part Number: 04-0045-02 Rev-A Document Order number: 9032539 Author: Bruce Jordan Editor: Carre Gibson Illustrator: Michael Fornalski Cover Designer: Michael Fornalski Date Revision September 1997 04-0045-01 Rev-A March 1998 04-0045-02 Rev-A...

  • Page 9: Table Of Contents

    Switch Installation and Setup ........
  • Page 10 Connecting to Local Switch Client Through a PVC ....... . .
  • Page 11 Index............I-1 SmartCell 6A000 User Guide xi...
  • Page 12 TABLE OF CONTENTS SmartCell 6A000 User Guide...

  • Page 13: List Of Figures

    ZeitNet Cabletron 6A000 MIB object identifier example ........B-4...
  • Page 14 List of Figures xiv SmartCell 6A000 User Guide...

  • Page 15: List Of Tables

    Zeitnet proprietary MIB groupings ...........B-4 SmartCell 6A000 User Guide xv...
  • Page 16 List of Tables SmartCell 6A000 User Guide...

  • Page 17: Introduction

    1 INTRODUCTION Welcome to the SmartCell 6A000 User Guide. The SmartCell 6A000 ATM switch is a module that fits into the SmartSwitch 6000 chassis. You can install as many as five SmartCell 6A000 switches into a SmartSwitch 6000 chassis (using the 6C305-3 power supply). The module is hot swappable, meaning that you can install and remove it without turning off or disconnecting the chassis.
  • Page 18 Introduction 1-2 SmartCell 6A000 User Guide...

  • Page 19: Switch Installation And Setup

    Depending on the configuration ordered, your switch looks similar to one of the units in the drawing in Figure 2-1. The 6A000-04, shown on the left, has four I/O modules. The 6A000-02, shown on the right, has two I/O modules; the empty I/O module positions are covered by metal blanks.

  • Page 20: Figure 2-1 6A000-04 And 6A000-02 Front Panels

    Inspecting the Switch Figure 2-1 6A000-04 and 6A000-02 front panels Inspect the switch and make certain that its configuration corresponds to what was ordered. Also, make certain that the input/output (I/O) modules are of the correct type and number (See Table 2-1).

  • Page 21: Ds3 And E3 I/O Module Configuration

    INSTALLING THE SWITCH The SmartCell 6A000 is hot swappable, meaning that you can install and remove it without turning off or unplugging the SmartSwitch 6000 chassis. You can install as many as five switch modules in each chassis (using the 6C205-3 power supply).
  • Page 22 Open the ejectors at the top and bottom of the switch module. •• With the LEDs at the top, align the top and bottom of the SmartCell 6A000 with the tracks in the slot. T• Slide the switch into the chassis. The switch module obscures the view of the tracks at the bottom of the chassis, so be sure to look at that area as you begin to slide the switch into the chassis.

  • Page 23: Configuring The Switch

    Figure 2-2 Installing the SmartCell 6A000 CONFIGURING THE SWITCH Initial configuration of your SmartCell 6A000 switch consists of setting the name, Ethernet IP address, and subnet mask. Once these tasks are complete, the switch can be reached through your Ethernet network for additional configuration and administration.
  • Page 24 For information about adapter wiring configurations, see Appendix A, "Specifications." T• Plug the other end of the UTP cable into the SmartCell 6A000 female RJ-45 jack labeled Terminal, located on the front panel (see Figure 2-3). Q• Connect the switch to your network by plugging a UTP cable into the SmartCell 6A000 female RJ-45 jack labeled Ethernet, located near the center of the switch's front panel (see Figure 2-3).

  • Page 25: Figure 2-3 6A000 Console And Network Connections

    Start the dumb terminal or PC and its terminal emulation software. •• As soon as power is applied to the SmartCell 6A000, the module emits a series of diagnostic messages. If you inserted the module into a chassis that was turned off, turn it on now to see the diagnostics.

  • Page 26: Using The Console

    Using the SmartCell 6A000 console Installing and getting started with the Windows-based SmartSwitch ATM Administrator application USING THE CONSOLE Use the SmartCell 6A000 console interface to configure and manage your switch. The following is a description of the console interface and its operation. 2.5.1 Console Commands 2p›F...
  • Page 27 Switch Installation and Setup : Start a process on the switch; for example, start the LAN Emulation Configuration Server. start : Restart a process on the switch; for example, restart a client. restart : Remove assigned values; for example, flush a route table.

  • Page 28: Console Time-Out

    The console can be configured to exit if it does not sense a key stroke within a defined length of time. By default, the SmartCell 6A000 is set to never time-out (value = 0). To activate the time-out feature, use the...

  • Page 29: Ambiguous Commands

    If you enter part of a command, and that part is not unique, the console displays a numbered list of possible matching commands. For example, entering show pnnin “pnnin.” In response, the SmartCell 6A000 displays a list of the possible commands: < “pnnin” is ambiguous SmartCell ZX # show pnnin...

  • Page 30: Smartswitch Atm Administrator

    Perform drag and drop operations Manage all switches from one console Perform transactions across multiple switches (for example, create an ELAN when the servers are not co-located 2-12 SmartCell 6A000 User Guide : a3 : 39:00:00:00:00:00:00:00:00:00:14:72:80 :exterior Switch Installation and Setup...

  • Page 31: Installation Steps

    2.6.1 Installation Steps The installation process for SmartSwitch ATM Administrator is essentially the same for all the supported operating systems. Follow these instructions for installation on NT 4.0, NT 3.5.1, or Win95. SmartSwitch ATM Administrator SmartCell 6A000 User Guide 2-13...

  • Page 32: Starting Smartswitch Atm Administrator The First Time

    In the SmartCell ZX Network Management Tools (Common) program group, double click on the icon labeled SmartSwitch ATM Administrator. The SmartSwitch ATM Administrator Login dialog box appears. 2-14 SmartCell 6A000 User Guide Default Password admin guest Switch Installation and Setup...

  • Page 33: Accessing Online Help

    Click the Contents tab to show the Table of Contents of the online help. Click on the topic you wish to read about. † Click the Index tab to select from an alphabetical list of help topics. † Click the Find tab to search for a particular topic. SmartSwitch ATM Administrator SmartCell 6A000 User Guide 2-15...
  • Page 34 SmartSwitch ATM Administrator Switch Installation and Setup 2-16 SmartCell 6A000 User Guide...

  • Page 35: Ip Over Atm And Lane

    3 IP OVER ATM AND LANE This chapter describes working with the SmartCell 6A000 IP over ATM VLAN and emulated LAN capabilities. At the end of this chapter you will be able to use your SmartCell 6A000 switch to •...
  • Page 36 Your end nodes do not need to be physically attached to the switch that contains the ARP server. For example, an end station is connected to a 6A000 switch that is connected through a route to the switch containing the ARP server . No special...

  • Page 37: Atm Addressing For Ip Over Atm

    3.1.1 ATM Addressing for IP over ATM The SmartCell 6A000 provides a default format for ATM addresses used by IP over ATM. The default format is constructed as follows: netprefix + two zero bytes + IP address of the device (in hex) + a trailing zero byte Where the netprefix is constructed from 39 + nine zero bytes + the last three bytes of the device’s MAC address...
  • Page 38 SmartCell ZX # start lecs NOTICE - 'LECS' ***** LECS started ***** SmartCell ZX # Create an ELAN on your SmartCell 6A000 switch by executing the following is an example. SmartCell ZX # add elan <1 is used instead of the default, (0) ELANNumber(0) : 1 <ELAN is named Marketing instead of the default, (ELAN000)
  • Page 39 Your ELAN is now operational. Additional ELANs can be created in the same way. See Chapter 4, “Switch Administration,” for information about SmartCell 6A000 switch operations and maintenance. While it is possible for a single ELAN on the SmartCell 6A000 switch to support Note multiple subnets, in general, switch performance is best (and management easiest) when the “One-subnet-per-ELAN”...

  • Page 40: Atm Addressing For Lan Emulation

    It is important to understand the concept of SmartCell 6A000 switch client connections. A client connection is actually a connection between the VLAN and the SmartCell 6A000 CPU; this CPU connection appears as if the switch is an end station on the VLAN. The SmartCell 6A000 uses local clients to connect itself to the VLANs that it supports.
  • Page 41 Similarly, VLAN membership (and the reachability) of a SmartCell 6A000 on any particular VLAN depends upon whether the SmartCell 6A000 has a local client connection for that VLAN. Clients are created using the command...
  • Page 42 %•F"›amV˜"m˜'h¤d"›F=˜/"2 ˜˜,6˜3¦F•˜":1˜"m=˜/"2' 3-8 SmartCell 6A000 User Guide...

  • Page 43: Switch Administration

    CONFIGURATION Once your SmartCell 6A000 ATM switch is up and running or you have made extensive changes to the configuration, you should back up the switch configuration. If the flash RAM gets formatted or corrupted, you can restore the switch configuration from the backup file.

  • Page 44: Atm Routing

    ATM Routing The switch stores the IP address of the TFTP server, the path, and the backup file name. The next time you enter the commands, these values are presented as the default IP address and path. For example, when you...

  • Page 45: Iisp Routing Considerations

    SmartCell 6A000. Conversely, there must be a SmartCell 6A000 that has a direct physical link (and a route over that link) to the IISP device. The following two examples illustrate this point.

  • Page 46: Figure 4-1 Iisp Route Across Pnni Domain

    Figure 4-1 IISP route across PNNI domain A second IISP device (Switch D) is added behind Switch A. If Switch D also needs to reach Switch C for LECS support, you must define additional IISP routes between Switches D and C, B and D, and A and D. Figure 4-2 shows the typical “route to every point reached”...

  • Page 47: Uni Routes

    00:11:22:33:44:55) to port A2 of the SmartCell 6A000. If the adapter does not support ILMI or its ILMI is incompatible with the SmartCell 6A000, you must create a static UNI route between the adapter and port A2 of the SmartCell 6A000.

  • Page 48: Route Metrics

    MaximumCellTransferDelay(-1) CellDelayVariation(-1) CellLossRatioForCLP=0(-1) CellLossRatioForCLP=0+1(-1) CellRateMargin(-1) VarianceFactor(-1) SmartCell ZX # 4-6 SmartCell 6A000 User Guide add ATMRoute < 1st pair member, we accept the default : cbr : 200 : 1000 : 750 < 2nd pair member, we set as incoming...

  • Page 49: Ip Routing

    IP ROUTING The SmartCell 6A000 switch provides limited IP routing. IP routing allows switches that are not connected directly to Ethernet to communicate with an Ethernet-based network management system (NMS). The connection is made by adding IP routes on the non-connected switches that specify a client on a connected switch as their gateway to the Ethernet.
  • Page 50 IP Routing SmartCell 6A000 IP routing performance is inadequate for routing between Note VLANs. If you need to create routes between VLANs on your SmartCell 6A000, use a router equipped with an ATM interface. Consult Cabletron Customer Support for recommended routers.

  • Page 51: Events And Alarms

    EVENTS AND ALARMS The SmartCell 6A000 switch records and reports its operation in real-time through the use of events and alarms. An event is an occurrence of a significant activity. For instance, a port going down or a client joining an ELAN are examples of events.

  • Page 52: Viewing Events And Alarms

    Object — The object affected by the event (port, LEC, and so on) • Description — Brief message describing the event Event messages can be automatically displayed on the SmartCell 6A000 console. Use the command to display events on the console as they occur: SmartCell ZX # set eventdisplay...

  • Page 53: Deleting Events And Alarms

    The SmartCell 6A000 supports Permanent Virtual Circuits (PVCs), both point-to-point and point-to-multipoint. Use PVCs to connect devices (that do not support SVCs) to a switch’s local client. Also, use PVCs to make connections through the SmartCell 6A000 between devices that support only PVCs.

  • Page 54: Point-To-Point Pvcs

    4.5.1 Point-to-Point PVCs The procedure for setting up a PVC connection between two end nodes through the SmartCell 6A000 consists of specifying the ports and the virtual path and virtual channel identifiers (VPI and VCI). to define a traffic descriptor to use with the PVC...
  • Page 55 <this is the backward descriptor <we set everything to zero Sust Cell Rate Max Burst Size (Kb/s) (Kb/s) CLP_0+1 CLP_0 CLP_0+1 CLP_0 1585 : pmp : a1 : 101 : b2 : 101 PVC Connections Type CLP_0+1 SmartCell 6A000 User Guide 4-13...

  • Page 56: Connecting To Local Switch Client Through A Pvc

    Connecting to Local Switch Client Through a PVC All PVC connections to the SmartCell 6A000 local clients use B4 (the CPU port) as the HighPort. Follow these instructions to connect an end node to a SmartCell 6A000 local client through a point-to-point PVC. to create the PVC.

  • Page 57: Table 4-1 Values For Vpi And Vci

    PVC. If the VPI and VCI values do not fit one of the indexed combinations, the SmartCell 6A000 uses the closest matching indexed combination. If you need to use values for VPI and VCI that do not fall within the range of one of the preconfigured indexed combinations, use the command to replace one of the preconfigured combinations.
  • Page 58 PVCs can be configured for port A1 using VPI values from 0 to 7 and VCI values from 0 to 511. Do not set the VCI part of the VCCMask to fewer than 5 bits. Note Note Do not change the VCCMask for the CPU port (B4). 4-16 SmartCell 6A000 User Guide Current pnni10 symmetric private <VPI on port A1 can now be any 3-bit number...

  • Page 59: Traffic Management

    SmartCell 6A000 user data cells are classified according to the state of a cell loss priority (CLP) bit in the header of each cell. A CLP 1 cell has a lower priority than a CLP 0 cell and is discarded first. Source traffic descriptors can specify CLP 0 cell traffic, CLP 1 cell traffic, or the aggregate CLP 0+1 traffic.
  • Page 60 Traffic Descriptor with CLP, no Tagging, and SCR Traffic Descriptor with CLP, Tagging, and SCR Traffic Descriptor with CLP and best effort 4-18 SmartCell 6A000 User Guide command to view all currently defined traffic descriptors. Sust Cell Rate Max Burst Size...

  • Page 61: Call Admission Control Policy

    Call Admission Control Policy Call Admission Control (CAC) policy defines the bandwidth allocation scheme used by the CAC when setting up connections. The SmartCell 6A000 offers three schemes that can be set on a per-port, per-service class basis, • Conservative •...
  • Page 62 SmartCell ZX # The SmartCell 6A000 performs buffering using a shared-memory architecture. Buffer space is divided into queues for each QoS. In turn, ports are allocated some portion of each of the QoS queues. This allocation is controlled on a...
  • Page 63 1000 20 16384 2000 1000 20 16384 2000 1000 20 16384 : a3 : 1000 < Min for CBR queue : 10000 < Max for CBR queue Traffic Management command set porttrafficcongestion , enter the SmartCell 6A000 User Guide 4-21...

  • Page 64: Efci, Epd, And Rm Thresholds

    4.6.3 EFCI, EPD, and RM Thresholds To control switch congestion, the SmartCell 6A000 implements standard resource management cell (RM-cell) marking, explicit forward congestion indicator cell marking (with backward RM cell marking), and early packet discard (EPD). These congestion control schemes are triggered when the number of cells within shared memory reaches user-definable thresholds.

  • Page 65: Upgrading And Changing Software

    Switch Administration Along with EFCI and backward RM cell marking, the SmartCell 6A000 uses standard RM cell marking. The switch discard threshold ( show switchtrafficcongestion point at which the switch considers itself congested and starts marking RM cells. The switch discard threshold is not user configurable and is shown only for Note information.

  • Page 66: Boot Load Commands

    POST on or off: ponf Changes start-up action: either run POST before running switch software or skip POST and go directly to switch software. 4-24 SmartCell 6A000 User Guide Switch Administration Parameters = set boot load image 0 as default chpi 0...

  • Page 67: Upgrading Boot Load Software

    Follow the steps below to upgrade the switch boot load software. Set up the TFTP/Bootp server software on a workstation. Connect both the TFTP/Bootp server and the SmartCell 6A000 to your Ethernet network. Make sure that the TFTP/Bootp server can be reached by the SmartCell 6A000 Ethernet interface.
  • Page 68 If the new boot load software passes the validity checks, it is marked as the new default image. In the example above, boot load image 1 becomes the new default image. Reboot the SmartCell 6A000. The following message appears on the terminal screen: Preparing to run Default Boot Load Software: 1...

  • Page 69: Upgrading Post Diagnostic Software

    New Default Primary Image Number: 0 => Reboot the SmartCell 6A000. Boot load image 0 is now used as the default image. Preparing to run Default Primary Image: 0 Enter 0 or 1 to override and force one of these primary image sectors to run: 4.7.4...

  • Page 70: Upgrading Switch Operating Software

    Command.” Set up the TFTP/Bootp server software on a workstation. Connect both the TFTP/Bootp server and the SmartCell 6A000 to your Ethernet network. Make sure that the TFTP/Bootp server can be reached by the SmartCell 6A000 Ethernet interface. Connect a dumb terminal (or PC running terminal emulation software) to the SmartCell 6A000 Terminal port.

  • Page 71: Using The Update Firmware Command

    When the 6A000 switch is started (or rebooted), it copies its operating software from flash RAM to the CPU’s program memory. When a hot upgrade is performed, the image in flash RAM is erased and replaced with the new software image.

  • Page 72: Saving Core Dumps

    SAVING CORE DUMPS The SmartCell 6A000 core dump feature allows you to specify a local Ethernet host where, in the event of a system failure, the SmartCell 6A000 sends a copy of its memory. SmartCell 6A000 system memory is saved to two files, one containing CPU memory (core_cpu), the other common memory (core_cmn).
  • Page 73 Saving Core Dumps < “y” to enable core dump feature < IP address of my TFTP server < full path name for core dump files < login name on the server < password SmartCell 6A000 User Guide 4-31...
  • Page 74 Saving Core Dumps If a system failure occurs while the core dump feature is enabled, the SmartCell 6A000 console appears similar to the example below. The SmartCell 6A000 then begins sending images of its memory to the core dump files on the TFTP server.

  • Page 75: Troubleshooting

    You have configured an IP over ATM VLAN, but your network applications are not working. Use these questions and tests to help determine the cause of the problem. Check for connectivity: Try pinging between end nodes and from the SmartCell 6A000 (using ) to its end nodes. If you cannot ping, check physical connectivity (disconnected cable and so ping on).

  • Page 76: Troubleshooting Lan Emulation

    You have configured an Emulated LAN and your network applications are not working. Use these questions and tests to help determine the cause of the problem. Check for connectivity. Try pinging between end nodes. Ping from the SmartCell 6A000 (using ) to its end nodes. If you cannot ping, check physical connectivity (disconnected cable start ping and so on).

  • Page 77: Troubleshooting Pnni Links

    TROUBLESHOOTING CONGESTION If the bandwidth of your SmartCell 6A000 begins to decrease, and if connections are being lost or packets are being dropped at a high rate, it’s possible that your switch is becoming congested. Congestion can occur on the port level, the global switch level, or both levels.

  • Page 78: Diagnosing Congestion

    5.4.2 Global Congestion Is the total cell drop rate equal to the Unknown VC cell drop rate? • If yes, the switch is improperly set up. Check the switch configuration. • If no, this indicates global congestion. Continue. Set the porttrafficcongestion Guidelines”...

  • Page 79: Port Congestion

    VCs dropped. Is the difference for cells dropped equal to the difference for VCs dropped? • If yes, the switch is improperly set up. Check the switch configuration. • If no, this indicates port congestion. Continue. Enter the command for this port.
  • Page 80 Troubleshooting Congestion Troubleshooting 5-6 SmartCell 6A000 User Guide...

  • Page 81: Appendix A Specifications

    APPENDIX A SPECIFICATIONS This appendix describes SmartCell 6A000 switch hardware, product features, technical specifications, and adapter pin-out descriptions. "•s )832:˜6"2'/ This section describes the hardware components of the SmartCell 6A000 ATM switch. Table A-1 Front panel LEDs Function FAIL (red) Normally OFF;...

  • Page 82: Technical Specifications

    Figure A-1 Front panel "•¢ :'%+2,%"/˜96'%,),%":,329 Table A-2 Hardware Specifications Specification Value Processor i960CF, 33 MHz Switching engine 2.5 Gbps, non-blocking A-2 SmartCell 6A000 User Guide FAIL STATUS POWER FAIL STATUS RX DATA POWER RX ENET TX DATA TX ENET...
  • Page 83 Specifications Table A-2 Hardware Specifications (Continued) Specification Value Max I/O ports 7 for 6A000-02; 15 for 6A000-04 Switch latency 10 microseconds CPU DRAM memory 32 MB Buffer memory (cells) 32 K flash memory 8 MB Serial port RS-232c compliant; RJ-45 connector Ethernet port IEEE 802.3 compliant;...
  • Page 84 75 ohm 34.3 Mbps coax nonchannelized Table A-5 Protocols Standards and Specifications Protocol Signaling ATM routing protocols LAN protocols A-4 SmartCell 6A000 User Guide Connector Max. Tx Min. Tx Power power RJ-45 BNC, female BNC, female BNC, female Standard ATM Forum UNI 3.0...
  • Page 85 AToM MIB (RFC 1695) AToM2 MIB (pre-standard) LANE MIB (ATM Forum) ILMI 4.0 MIB (ATM Forum) IP over ATM MIB (pre-standard) PNNI MIB Switch hardware MIB DB-9 Pin DB-9 Description Receive Transmit Ground Technical Specifications SmartCell 6A000 User Guide A-5...
  • Page 86 Technical Specifications Specifications A-6 SmartCell 6A000 User Guide...

  • Page 87: B.1 Mib, Smi, Mib Files And Internet Mib Hierarchy

    APPENDIX B AGENT SUPPORT This appendix briefly describes the support provided for managing the SmartCell 6A000 using Simple Network Management Protocol (SNMP). MIB, SMI, MIB FILES AND INTERNET MIB HIERARCHY A MIB (Management Information Base) is the term used to represent a virtual store of management data on a device.

  • Page 88: Zeitnet Cabletron Proprietary Mibs

    The location of some of ZeitNet proprietary MIBs in the Internet hierarchy is shown in Figure B-2. All nodes starting with “zn” represent Zeitnet objects. The private ZeitNet MIB is represented by the object identifier 1.3.6.1.4.1.1295, or iso.org.dod.internet.private.enterprise.zeitnet. The ZeitNet proprietary MIBs include the subtrees shown in Figure B-2. Appendix B-2 SmartCell 6A000 User Guide root joint ISO/CCITT...

  • Page 89: Relation Between Object Identifier And The Represented Value

    LEC. atomMIB Private enterprise ZeitNet 1295 znProducts znManagedObjects znCommonObjs MIB, SMI, MIB Files and Internet MIB Hierarchy Label from the root to this point is 1.3.6.1 znSwitchObjedcts 3333 znAdminPolicyVal znTrapObjs znIpAtm SmartCell 6A000 User Guide Appendix B-3...

  • Page 90: B.1.3 Supported Protocols

    Figure B-3 ZeitNet Cabletron 6A000 MIB object identifier example B.1.3 Supported protocols The SmartCell 6A000 supports Simple Network Management Protocol (SNMP). Both the SNMPv1 and SNMPv2c formats of the protocol are supported. B.1.4 Supported SMI Formats Zeitnet proprietary MIBs are defined using SNMPv2 format of the SMI.

  • Page 91: Smartcell 6A000 Mib Support

    1.3.6.1.4.1.1295.2.3333.12 znEventTable 1.3.6.1.4.1.1295.2.3333.13.2 znEventAlarmTable 1.3.6.1.4.1.1295.2.3333.13.5 B.1.6 SmartCell 6A000 MIB Support The SmartCell 6A000 is shipped with the following MIBs: • MIB II (RFC 1213) • Interface Table MIB (RFC 1573) • AToM MIB (RFC 1695) • AToM2 MIB (pre-standard) •...

  • Page 92: B.1.7 Mib Exceptions

    Along with the MIBs, the diskette also contains a README file and the release Note note. B.1.7 MIB Exceptions With the current implementation of MIB files, conformance to ATM standards for the SmartCell 6A000 ATM switch includes the following exceptions. Non-Conformance • atmInterfaceIlmiVpi — Read-only •...

  • Page 93: Managing The Smartcell 6A000

    SmartCell 6A000 and the NMS is the SmartCell 6A000 Ethernet interface. Use the to find the IP address of the SmartCell 6A000. An NMS can use this IP address to reach the SmartCell 6A000 through Ethernet. An NMS can also manage the SmartCell 6A000 through one of its ATM ports if the SmartCell 6A000 has a client connection into a VLAN or emulated LAN.
  • Page 94 Managing the SmartCell 6A000 Agent Support Appendix B-8 SmartCell 6A000 User Guide...

  • Page 95: C.1 Telephone Assistance

    APPENDIX C TECHNICAL SUPPORT This appendix tells you what to do if you need technical support for your SmartCell 6A000 switch. Cabletron offers several support and service programs that provide high-quality support to our customers. For technical support, first contact your place of purchase. If you need additional assistance, contact Cabletron Systems, Inc. There are several easy ways to reach Cabletron Customer Support and Service.

  • Page 96: C.5 Hardware Warranty

    Cabletron offers an out-of-warranty repair service for all our products at our Santa Clara Repair Facility. Products returned for repair will be repaired and returned within 5 working days. A product sent directly to Cabletron Systems, Inc. for repair must first be assigned a Return Material Authorization (RMA) number. A product sent to Cabletron Systems, Inc., without an RMA number displayed outside the box will be returned to the sender unopened, at the...

  • Page 97: Appendix D Acronyms

    Application Programming Interface Address Resolution Protocol ASCII American Standard Code for Information Interchange Asynchronous Transfer Mode Available Cell Rate Bridged Ethernet Bit Error Ratio (Rate) B-ICI Broadband Inter-Carrier Interface B-ISDN Broadband Integrated Services Digital Network SmartCell 6A000 User Guide Appendix D-1...
  • Page 98 Congestion Indicator Cell Loss Priority Cell Loss Ratio CMIP Common Management Information Protocol Communication Class of Service Customer Premise Equipment Central Processing Unit Cyclic Redundancy Check Cell Relay Service Convergence Sublayer Cell Transfer Delay Appendix D-2 SmartCell 6A000 User Guide Acronyms...
  • Page 99 EISA Extended Industry Standard Architecture ELAN Emulated Local Area Network Electro-Magnetic Interference Enterprise Network Roundtable End of Frame Early Packet Discard EPROM Erasable Programmable Read-Only Memory Electro-Static Device End System Identifier Expansion Switch Module SmartCell 6A000 User Guide Appendix D-3...
  • Page 100 Generic Cell Rate Algorithm Generic Flow Control Header Error Check IEEE Institute of Electrical and Electronic Engineers ICMP Internet Control Message Protocol Identification Number Information Element IETF Internet Engineering Task Force IISP Interim Inter-Switch Signaling Protocol Appendix D-4 SmartCell 6A000 User Guide Acronyms...
  • Page 101 ISDN Integrated Service Digital Network JPEG Joint Photographic Experts Group KB/S Kilobits per second Local Area Network LANE LAN Emulation LAN Emulation LE-ARP LAN Emulation-Address Resolution Protocol LANE Client LECS LAN Emulation Configuration Server SmartCell 6A000 User Guide Appendix D-5...
  • Page 102 Metropolitan Area Network MB/S Megabits per second Maximum Burst Size Minimum Cell Rate Management Information Base Multi-Mode Fiber Multi-Point Main Switch Module Maximum Transfer Unit NAKS Negative Acknowledges NDIS Network Driver Interface Specification Appendix D-6 SmartCell 6A000 User Guide Acronyms...
  • Page 103 Operations, Administration, Maintenance and Provisioning OC-1 Optical Carrier 1 OC-N Optical Carrier n (where "n" is an integer) Open Data-link Interface Out of Band Open Systems Interconnection Personal Computer Priority Control Peripheral Component Interconnect Peak Cell Rate SmartCell 6A000 User Guide Appendix D-7...
  • Page 104 Quality of Service QSAAL Q-Signaling ATM Adaptation Layer. (Q represents the Q-series of the ITU-T (International Telecommunications Union). Read-Only Access Random Access Memory Routing Control Channel Raw Cell Received Receive Deactivated Request for Comment Appendix D-8 SmartCell 6A000 User Guide Acronyms...
  • Page 105 Synchronous Transport Module n - concatenated (where ‘n' is an integer) Shielded Twisted Pair STS-1 Synchronous Transport Signal 1 STS-N Synchronous Transport Signal n (where ‘n' is an integer) STS-NC Synchronous Transport Signal n - concatenated (where ‘n' is an integer) SmartCell 6A000 User Guide Appendix D-9...
  • Page 106 Trivial File Transfer Protocol Type, Length and Value Unspecified Bit Rate UNI Management Entity User-Network Interface Unnumbered Poll Usage Parameter Control UTOPIA Universal Test and Operations Physical Interface for ATM Unshielded Twisted Pair Appendix D-10 SmartCell 6A000 User Guide Acronyms...
  • Page 107 Variable Bit Rate/Non-real Time Virtual Circuit Virtual Channel Connection Virtual Channel Identifier Virtual Channel Link VLAN Virtual LAN Virtual Path Virtual Path Connection Virtual Path Identifier Virtual Private Network Virtual Tributary Wide Area Network SmartCell 6A000 User Guide Appendix D-11...
  • Page 108 Acronyms Appendix D-12 SmartCell 6A000 User Guide...

  • Page 109: Index

    EFCI... 4-22 EPD... 4-22 global congestion port congestion... 5-5 ... 4-17 affected... 4-25 ... 4-23 ... 4-25 ... 4-17 4-19 policy... 4-19 4-27 ... 3-6 ...2-5 ... 2-6 ... 4-22 ... 5-4 ... 4-22 ... 5-4 SmartCell 6A000 User Guide I-1...
  • Page 110 ... 2-8 DS3... 2-3 empty cell... 2-3 framing... 2-3 length ... 2-3 mode ... 2-3 scrambling... 2-3 timing... 2-3 I-2 SmartCell 6A000 User Guide E3...2-3 empty cell...2-3 mode...2-3 scrambling...2-3 timing ...2-3 early packet discard EFCI ...4-22 ELAN adding a client...3-4...
  • Page 111 4-21 operator... 2-8 switch-attribute outgoing metric ... 4-6 ... 3-3 ... 5-1 ... 5-2 ... 5-2 ... A-5 ... B-7 ... 4-17 ... 4-6 ... B-6 ... B-6 LANs... 3-6 ... 2-8 SmartCell 6A000 User Guide I-3...
  • Page 112 ... 4-21 thresholds... 4-21 unspecified bit rate...4-21 queues...4-21 queue thresholds... 4-21 remove... 2-8 repair services... C-2 resource management cells... 4-22 I-4 SmartCell 6A000 User Guide restart restore ...4-1 RJ-45 to DB-9 RM cells ...4-22 route metrics ...4-6 administrative incoming ...4-6...
  • Page 113 VCC mask index ... 4-14 VCI bits ... 4-14 viewing events and alarms ... 5-4 ... 5-4 ... 5-2 address...4-5 4-29 ... 4-29 ... 4-28 ...4-27 ... 4-27 ...4-25 software... 4-25 ... 2-8 ... 4-14 ... 4-10 SmartCell 6A000 User Guide I-5...
  • Page 114 Index viewing route metrics ... 4-7 non-zero values... 4-14 bits... 4-14 VPI/VCI pairs... 4-14 ZeitNet Cabletron proprietary MIBs ... B-2 I-6 SmartCell 6A000 User Guide...
