H1 Axial Piston Single Pumps, Size 045/053
Control Options
©
Danfoss | May 2017
Case Gauge Port M14
The drain port should be used when the control is mounted on the unit's bottom side to flush residual
contamination out of the control.
MDC schematic diagram
M14
M5
Lever
MDC-controls are available with an integrated lever.
M4
M3
P005 701
11063344 | BC00000059en-US1001 | 23
