Technical Information
H1 Axial Piston Single Pumps, Size 045/053
Master Model Code
© Danfoss | May 2017
A B Z D
H1P A A
S – Charge pump
12 cm³/rev [0.73 in³/rev]
B
No charge pump, external charge supply (Align with options: E and T)
N
T – Filtration (Align with option G: Endcap selection)
Suction filtration (see
L
Remote full charge flow filtration
P
External charge flow filtration (Align with options: N and S)
E
Integral charge full flow filtration with Bypass sensor, no filter cartridge
N
V – Charge pressure relief setting
18 bar [261 psi]
18
20 bar [290 psi]
20
22 bar [319 psi]
22
24 bar [348 psi]
24
26 bar [377 psi]
26
28 bar [406 psi]
28
30 bar [435 psi]
30
32 bar [464 psi]
32
W – Special hardware features
EDC / FNR / MDC valve plate
PN
NFPE valve plate (Align with options: D and E)
P1
NFPE / FDC / AC valve plate and speed ring on the cylinder block
P2
EDC / FNR / MDC valve plate with speed ring on the cylinder block (Align with options: D and E )
P4
MDC / EDC / FNR valve plate with MDC handle
H1
X – Paint and nametag
Black paint and Danfoss nametag
NNN
F E G H J K
Suction filtration, option L for H1P 045/053 S
Not to be used for NFPE, AC and FDC controls.
M N S T V W
on page 62)
11063344 | BC00000059en-US1001 | 15
X Y
