Danfoss H1P 045 Technical Information page 13

Technical Information
H1 Axial Piston Single Pumps, Size 045/053
Master Model Code
© Danfoss | May 2017
A B Z D
H1P A A
G – Endcap options (Twin port, ISO 6162 split flange ports)
K: Auxiliary mounting pad 11 926 O-ring ports with options: M + N and T below:
Align the option
Code With pressure limiter
Suction Remote or external charge
filtration supply for full charge flow
filtration
–
E5
–
E6
– –
E9
– –
F1
K: Auxiliary mounting pad ISO 6162 split flange ports with options M + N and T below:
Align the option
–
D6
–
D8
– –
F2
– –
F3
H – Mounting
ISO 3019-1, flange 101-2 (SAE B)
F
ISO 3019-1, flange 101-2 (SAE B), 2-bolt and speed sensor
J
J – Input shaft
ISO 3019-1, (SAE-C, 17 teeth splined shaft, 12/24 pitch
A1
ISO 3019-1, outer Ø32 mm - 4 (SAE C, 14 teeth splined shaft 12/24 pitch)
G1
ISO 3019-1, (SAE-C, 13 teeth splined shaft, 8/16 pitch
G3
ISO 3019-1, outer Ø22 mm - 4 (SAE B, 13 teeth splined shaft 16/32 pitch)
G4
ISO 3019-1, outer Ø25 mm - 4 (SAE B, 15 teeth splined shaft 16/32 pitch)
G5
Conical keyed shaft end similar to ISO 3019-1 code 25-3, taper 1:8 (key not supplied with pump)
F2
K – Auxiliary mounting pad ISO 3019-1 (Align with option G: Endcap selection)
None
NN
Flange 82 - 2, outer Ø19 mm - 4 (SAE A, 11 teeth 16/32 coupling)
H1
Flange 82 - 2, outer Ø16 mm - 4 (SAE A, 9 teeth 16/32 coupling)
H2
Flange 101 - 2, outer Ø22 mm - 4 (SAE B, 13 teeth 16/32 coupling)
H3
Flange 101 - 2, outer Ø25 mm - 4 (SAE B-B, 15 teeth 16/32 coupling)
H5
Flange 101-2, outer Ø22mm-4 (SAE-B 14 teeth 12/24 coupling, not SAE standard)
S1
F E G H J K M N S T V W
Without pressure limiter(HPRV only)
Suction Remote or external charge
filtration supply for full charge flow
filtration
– —
– –
–
– –
– –
–
11063344 | BC00000059en-US1001 | 13
X Y
Shipping cover
