Technical Information
H1 Axial Piston Single Pumps, Size 045/053
Installation drawings

Dimensions H1P 045/053 Single

© Danfoss | May 2017
Twin Port, ORB, Remote Filter
Servo gauge port "M4"
Port ISO 11926-1 - 7/16-20
∅24.5 max clearance dia for fitting
System port "B"
Port ISO 11926-1 - 1 5/16-12
Z
Charge inlet port "S"
Port ISO 11926-1 - 1 5/16-12
A-A
(2x)
89.5 ±0.8
C L
Shaft
W (2:1)
1
2
P301 320
Control solenoid Connector "C1" & "C2"
Pin Assignment
1 Supply
2 Ground
Please contact Danfoss representative for specific installation drawings.
Y
238 ±2.5
186.3 ±1.2
177.3 ±1.2
2x 136.2 ±1.2
2x 120 ±1.2
Control solenoid connector "C2"
Deutsch DT04-2P
Paint free
See view W for pin out
41.1 ±0.8
W
C
A
C
A
B
B
Name plate
Paint free
System port "A"
Port ISO 11926-1 - 1 5/16-12
X
B-B
89.5 ±0.8
Shaft C L
OR
Pin
1
2
Mounting flange
Flange 101-2
Per ISO 3019-1 (SAE B)
19.8 ±2.1
9.7
0
-0.5
Case drain port "L4"
Port ISO 11926-1 - 1 1/16-12
1 ±0.5
R0.8 max
Paint free
C-C
91.2 ±0.8
Shaft C L
P700 33 051-1
Assignment
Ground
Supply
