Technical Information
H1 Axial Piston Single Pumps, Size 045/053

Master Model Code

10 | © Danfoss | May 2017
A B Z D
H1P A A
Displacement
3 3
45.0 cm [2.75 in ]
045
3 3
53.8 cm [3.28 in ]
053
A – Rotation
Left hand (counter clockwise)
L
Right hand (clockwise)
R
B – Product version
Revision code
C
Z – Port configuration
Inch, Customer O-ring port sealing according to ISO 11926-1
A
D – Controls — Electric Displacement Control (EDC)
Code Control type
EDC
A2
EDC
A3
EDC
A4
EDC
A5
EDC
E7
EDC
E8
– To be used for the control; — Not to be used for the control
D – Controls (continued) — Non Feedback Proportional Electric Control (NFPE)
Code Control type Voltage
NFPE 12 V
N1
NFPE 24 V
N2
NFPE
12 V
N3
NFPE 24 V
N4
NFPE 12 V
N5
NFPE
24 V
N6
NFPE 12 V
N7
NFPE 24 V
N8
Align with options: E: Displacement limiters and W: Special hardware.
F E G H J K
Voltage MOR
12 V —
24 V —
12 V
24 V
12 V —
24 V —
MOR
—
—
—
—
M N S T V W
CCO with key C
—
—
—
—
CCO with key C Angle sensor
— —
— —
—
—
—
—
11063344 | BC00000059en-US1001
X Y
DEUTSCH
Connector
DEUTSCH
Connector
