Servicing The Legend - Epilog Laser LEGEND 24EX 6000 Owner's Manual

Section 15:
In This Section
Service Module Location Diagram Legend 24 & 32 EX
Service Module Location Diagram #1 Legend TT
Service Module Location Diagram #2 Legend TT
Controller
Power Supply
Laser Module and RF Module Legend EX
Keyboard/Display
X-Beam
The Legend has been designed so that the owner of the equipment can do most
servicing. Most of the major components are modular, and can be replaced with a
Phillips head screwdriver or Allen wrench.
WARNING!
cord disconnected from the machine. Injury or death may occur if you attempt to
service the machine with power connected. The machine must be unplugged from
the wall socket providing electrical power. See the Diagram on the next page for the
location of the modular assemblies.
Servicing the
Legend
Any servicing of the equipment should be done with the power
177
