Mugs With Handles

The drive wheels are each two piece assemblies with three o-rings when fully
assembled.
accommodate a wide variety of mugs with handles. Not all mugs with handles
require the front drive wheels to be removed.
The photo below shows a mug with a handle properly positioned on the rotary
attachment,
removable portion of the
drive wheel shown in the
foreground.
Features
Removing the front part of the drive wheels enables the user to
with the
132
Loosen the two small thumb
screws on each wheel to remove
Fully assembled drive wheel.
Front drive wheel removed.
