Section 11: Standard and Optional Machine
Features
Park position for the secondary bearing block. The beam splitter/focus lens assembly has
been removed.
With the double head option installed, the secondary head bearing block reduces the
maximum stroke for single head mode to 30.5 inches (774 mm). The full 32 inches (812
mm) of stroke cannot be used if the double head attachment is installed as an option.
148
