Ethernet Network
Port: The Legend
uses a 10BaseT
style
and
crossover cable is
included
accessories kit that
came with your
laser. The port is
located
right side of the
machine, near the
rear. The network
parameters can be
set at the Legend,
and
doing so are in
Section
"Configuring
Your Computer –
Print
Installation".
Parallel Port:
machine, near the rear. The connector is recessed in a small rectangular cutout. Mate
the larger end of the printer cable to the Legend. The connector can be connected
only one way. Close the wire retainer clips around the ends of the cable.

Connecting the Exhaust

It is mandatory that an exhaust blower is hooked up and operating whenever your
laser system is running a job. The exhaust blower removes the dust, debris and smell
from the engraving cavity and exhausts it to the outside. You should never operate
your laser system without a properly working exhaust. Prior to the arrival of the
Epilog installation technician, a contractor should install the exhaust system. The
blower should be mounted outside your building for noise considerations. The
blower should not be more than twenty feet from the Legend. You should provide a
rigid, smooth duct from the blower to the vicinity of the Legend. The Legend systems
require 400 CFM at 6" of static pressure. Remember to put the blower switch for the
Legend EX lasers in an obvious and accessible place so it can be routinely switched
Section 1: Getting Started
connection
a network
in the
on the
Serial Port
Ne twork Port
Parallel Port
details for
4,
Driver
The connection point on the Legend is on the right side of the
6
