Section 10: Material Engraving Techniques
Extruded acrylic on the other hand is ideal if you are only going to vector cut.
Extruded is less expensive than cast and also has a lower melting point that produces
an almost flame finished edge when cut with the Legend.

Acrylic Engraving Techniques

Most acrylic is engraved on the backside to produce a look through effect from the
front surface. Remove the back protective cover layer before engraving. Leave the
top protective cover layer on so that it remains intact to prevent scratching while
handling the acrylic.
Since you are engraving the backside of the acrylic, you will need to reverse or mirror
your artwork before sending the job to the Legend.
Engrave the acrylic at a high speed and low power. A small amount of power is all it
takes to mark acrylic and high power levels tend to distort the acrylic when
engraving.
There are a large number of acrylic products that are painted on one side to add color
to the clear acrylic piece. You can engrave directly through the paint into the acrylic
for a very nice presentation effect. Leave the speed the same as if you are engraving
clear acrylic and turn up the power about 10% to get cleanly through the paint.
Applying too much power to the paint will melt it and cause distortion.

Acrylic Vector Cutting Techniques

Acrylic is one of the most popular cutting materials available. It comes in a variety of
colors and thickness. Laser cutting produces very nice edge quality without the need
for polishing or secondary clean up.
Use a Vector Grid to elevate the acrylic before cutting. Air Assist will greatly reduce
flaming when cutting acrylic and should always be used for this material.
Vectoring acrylic is similar to vectoring other materials.
determine the correct speed and power setting.
achieved with relatively slow speed and relatively high power. This combination
allows the laser beam to melt the edges of the acrylic and produce an almost flame
polished edge. Acrylics generally require only a single pass to cut, but thicker
acrylics may need two passes.
102
First, experiment to
Cutting acrylic is usually best
