Section 11: Standard and Optional Machine
Step 4 – Changing FACTORY Settings
On the LCD panel highlight SERVICE, press the ENTER key to display the options:
X Home:
Y Home:
X Rotary Home:
Y Rotary Home:
Auto Focus Adjust:
Laser Match:
Stamp Match:
Acceleration Compensation:
Ramp. Compensation:
Edge:
.
By turning the round knob on the LCD panel, you can adjust the coordinates of "X"
Home position. You may enter coordinates from + 200 to – 700. Decrementing this
number will have the affect of moving the red dot to the left, while increasing the
number will move the red dot to the right.
Note – The numbers in the Rotary Home boxes are not in decimals like the X-
coordinate values you obtained in Step 3 above. An X-coordinate value of -0.47
requires a setting of -470 in the X- Rotary Home
Features
Scroll to CALIBRATE. Press ENTER
Scroll down to X ROTARY HOME.
142
Move X/Y
Move Y Beam
Calibrate
Disable Axes
Reboot
