Air Assist (AA) Tubing Replacement
Parts Required
LC0643 - Tubing, Air, Vinyl, 5/16"OD x 3/16"ID (3.6')
Edge 12, 24 & 36, Pro 24 & 36
03/2023
www.epiloglaser.com
tech@epiloglaser.com
Tools Required
•
5/32" Allen wrench
•
Phillips head screwdriver
303-215-9171
.
Advertisement
Related Manuals for Epilog Laser Edge 12
Summary of Contents for Epilog Laser Edge 12
- Page 1 303-215-9171 Air Assist (AA) Tubing Replacement Edge 12, 24 & 36, Pro 24 & 36 Parts Required Tools Required LC0643 - Tubing, Air, Vinyl, 5/16”OD x 3/16”ID (3.6’) • 5/32” Allen wrench • Phillips head screwdriver 03/2023...
- Page 2 17000 AA Tubing Replacement Air Assist (AA) Tubing 5. Manually move the x-axis assembly to the middle of the engraver: Replacement AA Tubing Removal 1. Turn off the engraver. 2. Disconnect the engraver from power source. 3. Remove the right panel of the engraver: 6.
- Page 3 17000 AA Tubing Replacement 7. Disconnect the air assist tubing from 10. With the cable track free, pull it to the the camera bridge: left side of the machine to straighten 11. Disconnect the air assist tubing from the right side of the x-axis assembly: 8.
- Page 4 17000 AA Tubing Replacement 3. Curl the cable track into position and connect the air assist tubing to the The AA tubing and carriage camera USB camera bridge: cable may be secured with cable ties to the x-axis assembly in certain points. If this is the case, remove the cable ties and replace them once the installation of the AA tubing is complete.
- Page 5 17000 AA Tubing Replacement 6. Install and tighten the two (2) Phillips screws that secure the cable track to the carriage assembly: 7. Replace the right panel of the engraver. If further assistance is required, please contact Epilog Tech Support by phone at 303-215-9171, or by email at tech@epiloglaser.com.
