Section 8: Using the Epilog Legend Systems

Disable Axes

This feature allows you to disable the electrical current to the X and Y-axis motors.
Disabling the current allows you to move the carriage freely by hand to any point on
the engraving/cutting surface. Disabling the axes provides a means to quickly focus
on an uneven surface in either standard engraving mode or it is particularly helpful
for focusing when using the Rotary Attachment.
1. In the SERVICE menu highlight DISABLE AXES. Press ENTER. You are
now able to move the carriage freely without any resistance from the motors.
2. Pressing REBOOT is the only way to re-enable the axes.

Reboot

This feature reboots the Legend. All settings that have not been saved and all jobs in
memory will be lost when you reboot. Use this command to reboot the Legend after
you have used the DISABLE AXES command.

Lenses

A 2.0 inch lens is supplied as standard equipment on all Legend EX and TT systems.
The 2.0 inch lens is a very good general purpose lens that will fit the needs of most
engraving and cutting applications. There are three optional lenses available for the
EX line of lasers (these lenses are not available for the TT) to provide maximum
versatility for all of your engraving and cutting needs. The spot size of the laser beam
can be changed by installing a different lens assembly. A small spot size (achieved
with a 1.5 inch lens) is used for higher resolution engraving to achieve finer
engraving detail. A larger spot size (2.5 inch lens) can be used for lower resolution
engraving and is also used for vector cutting. The 4.0 inch lens is used for specialized
engraving applications and is a popular choice for cutting thick acrylic.
