Legend TT Specifications

Maximum Engraving Area
Maximum Material Thickness
Laser Control Display Panel
Intelligent Memory Buffer
Electrical Requirements
Max Ambient Room Air Temperature
Section 17: Specifications
Table Size
Operating Modes
Motion Control
Laser Source
Bearings
Belts
Resolution
Speed/Power Control
Print Interface
Standard Features
Size/Weight
Ventilation
Safety
194
24" x 12"
6"
27.25" x 13.25 "
4" x 3" LCD displays job graphic, stored file names, speed, power,
run time, and more. Drop down menus provide user control of all
laser settings, calibration, and special features.
Store unlimited files up to 32 MB. Rolling buffer allows files of
any size (32 MB and larger) to be engraved.
Optimized raster engraving, vector cutting, or combined
raster/vector mode.
High speed, continuous loop, DC servomotors using linear
encoding technology for precise positioning.
State-of-the-art, digitally controlled, air-cooled CO2 laser tubes are
fully modular, permanently aligned, and field
replaceable/upgradeable.
Ground and polished steel NeverWearTM bearing system.
Advanced B-style Kevlar precision drive belts.
User controlled choice of 150, 200, 300, 400, 600, or 1200 dpi.
Computer or machine controlled Speed and Power in 1%
increments to 100%. Vector color mapping links Speed and Power
setting to any RGB color.
10 Base T Ethernet or Parallel connections. Compatible with
Windows XP/2000.
Red Dot Pointer, Air Assist (pump optional), Auto Focus, 2" focus
lens, relocatable home, flash upgrade electronics.
32" wide x 24.5" deep x 15.75" high
100 lbs.
Auto-switching power supply accommodates 110 to 240 volt, 50 or
60 Hz, single phase, 15 amp AC.
External exhaust to the outside required. Output diameter at
machine is 4".
CDRH Class IIIa
90 degrees F (32 C) Max
