This chapter describes all the configurable features and their modes of operation,
and provides you with detailed information to let you configure the system using
the Configurator software.
For details on using the Configurator, see LT-995 TX3 Configuration and
Administration Manual.
This chapter explains
•
•
•
•
•
•
•
2.1

Inputs

Each card access controller has eight inputs to accommodate the following
special functions:
•
•
•
2.1.1 Request to exit for reader A or B
When this input is active, the system unlocks the lock and the handicap lock for
either reader A or B. In addition, the Unlock time timer starts. When the Unlock
time timer expires or the door contact associated with this card reader becomes
active, the doors lock.
The input is associated with the 'request to exit' function.
UL Listed TX3-CX Card Access System Installation Manual
Version 2
LT-6906 Copyright 2019
2
Inputs
Correlations
Access Criteria
Timers
Schedules
Holidays
System Status
Request to exit for reader A or B
Door sense for reader A or B
General purpose
