Figure 28. Controller output terminal sample connections
UL Listed TX3-CX Card Access System Installation Manual
Version 2
LT-6906
Copyright 2019
Door Strike 1
Maglock 1
External
power
supply
NC C NO NC C NO NC C NO NC C NO NC C NO NC C NO
OUTPUT 1
OUTPUT 2
Setup of the Card Access Controller
External
power
supply
Common
Normally
Common
Closed
18 AWG
OUTPUT 3
OUTPUT 4
OUTPUT 5
Normally
Open
18 AWG
OUTPUT 6
51
