4.7.3 Door sense
When the door is open this input is active and when the door is closed the input is
inactive.
4.7.4 General purpose input
The general purpose input is mainly used for establishing a correlation with a
specific output. When a general purpose input becomes active it is considered as
an event that correlates to either turn on or off a general purpose output, or to turn
on or off the high security mode. Other correlated events include different
functions such as forced entry, auto relock or interlock.
4.7.5 Active state
An active state is when the input circuit is considered active and is configured as
one of the following:
•
•
There are some restrictions in configuring the active state depending on what
kind of supervision is required.
If the input is not supervised the input is either 'open' or 'closed'. If the input is
supervised for 'open' the active state cannot be 'open'.
If the input is supervised for both 'open' and 'short' the active state cannot be
'open'.
4.7.6 Supervision requirement
Each input is configured for a specific type of supervision depending on your
particular installation requirements as follows:
•
•
•
•
Note:
4.7.6.1 No Supervision
When inputs are configured with no supervision, the active state is either 'open'
or 'short' as programmed.
UL Listed TX3-CX Card Access System Installation Manual
Version 2
LT-6906 Copyright 2019
open
short (default)
no supervision
supervise for open
supervise for short
supervise for both open and short
Set the Circuit Supervision in the Configurator software to match
the supervision type in your installation.
